DNP3 Configuration / Interoperability Guide

16.7.1

DNP v3.0 Device Profile

The following table provides a "Device Profile Document" in the standard format defined in the DNP 3.0
Subset Definitions Document. While it is referred to in the DNP 3.0 Subset Definitions as a "Document,"
it is in fact a table, and only a component of a total interoperability guide.
DNP V3.0
DEVICE PROFILE DOCUMENT
(Also see the DNP 3.0 Implementation Table in Section 4.6.2)
Vendor Name: DPS Telecom Inc.
Device Name: TempDefender G2
Highest DNP Level Supported:
For Requests: Level 3
For Responses: Level 3
Notable objects, functions, and/or qualifiers supported in addition to the Highest
DNP Levels Supported
(the complete list is described in the attached table):
The read function code for Object 50 (Time and Date), variation 1, is
supported.
Maximum Data Link Frame Size
(octets):
Transmitted: 292
Received: 292
Maximum Data Link Re-tries:
o None
x Fixed (3)
Requires Data Link Layer Re-tries:
Fixed (3)
o Always
o Sometimes
Requires Application Layer Confirmation:
o Never
o Always
o When reporting Event Data (Slave devices only)
x When sending multi-fragment responses (Slave devices only)
o Sometimes
Device Function:
o Master
xSlave
Maximum Application Fragment Size
(octets):
Transmitted: 512
Received: 512
Maximum Application Layer Re-tries:
x None
o Configurable
