BinaryOutput Status Points
Static Variation: Obj 10 Var 02 - BinaryOutput Status
Request function codes supported: 5 (direct operate), 6 (direct operate, no ack)
Supported relay output: Latch on, Latch off.
Point ID
0
1
2
Analog Inputs
The following table lists Analog Inputs (Object 30). It is important to note that Analog Inputs, Analog
Output Control Blocks, and Analog Output Statuses are transmitted through DNP as signed numbers.
Description
Control 1
Control 1
Control 1
99
Class
0
0
0
