4 ScanMaker i800 Supplement

Unlocking the Scanner

Before you can operate the scanner, you will need to unlock the scanner and TMA.
To unlock the scanner, follow the steps below:
1. Remove the yellow "Step 3" sticker from your scanner.
2. With the scanner power off, tilt the back left corner of the scanner to see the
locking switch at the bottom.
3. Push the locking switch to the position as indicated in the graphic below, with the
icon on the lock showing as "unlocked".
To unlock the TMA, follow the steps below:
1. Raise the scanner lid (TMA), then remove the yellow "Step 3" sticker from
the TMA.
2. Look for the locking switch at the base of the TMA.
3. Push the locking switch to the position as indicated in the graphic below, with the
icon on the lock showing as "unlocked".
Unlocked
Unlocked
