Specifications; Specifications / System Requirements - Microtek ScanMaker i800 Supplementary Manual

30 ScanMaker i800 Supplement

Specifications

Scanning Modes
Scanning Area
Resolution
Dynamic Range
Interface
Dimensions (L x W x H)
Net Weight
Voltage
Environment
Power supply
(AC/DC adapter)
System Requirements
General Requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 128MB RAM (256MB or more to use DIGITAL ICE Technology)
PC and compatibles
• Pentium III PC or higher with USB, Hi-Speed USB (USB 2.0), or FireWire (IEEE
1394) port
• Microsoft Windows 98SE, Me, 2000 or XP
Macintosh
• iMac or Mac G3/G4/G5 with built-in USB port or FireWire port
• Mac OS 9.x, OS X 10.2 - 10.3
Important
Specifications, bundles, and accessories are subject to change without notice.
Color, grayscale, and black-and-white in a single scanning
pass
True 48-bit color (approx. 281 x 10
16-bit grayscale (approx. 65,536 shades of gray)
Reflective: 8.5" x 14" (216 mm x 356 mm)
Transparent: 8" x 12" (203 mm x 305 mm)
Optical: 9600 dpi x 4800 dpi
Interpolated: 65,535 dpi (PC); 32,767 dpi (Mac)
4.0 Dmax
Hi-Speed USB (USB 2.0) and FireWire (IEEE 1394)
22.6" x 11.7" x 4.6" (576 mm x 297 mm x 118 mm)
14.1 lbs (6.4 kg)
AC 100V to 240V
1.2A Max; 47-63 Hz (Input)
15V/2.5A (Output)
Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
Manufacturer Model No.
FAIRWAY VE50-150A
12
colors)
Voltage
100V to 240V
