OSD Function Menus

SCREEN Menu

Press the "MENU" button once to display the SCREEN menu.
Four available options can be adjusted: CLOCK, PHASE, H-POS,
and V-POS.
Function Description
CLOCK Adjusts the number of pixels from the source video
PHASE Adjust the phase relative to the video H-sync signal
H-POS Moves the screen horizontally (left/right)
V-POS Moves the screen vertically (up/down)

GAIN CONTROL Menu

Press the "MENU" button twice to display the GAIN CONTROL
menu. Two available options can be adjusted: BRIGHTNESS
and CONTRAST.
Function Description
BRIGHTNESS Adjusts the level of brightness and darkness
CONTRAST Adjusts the RGB color pattern set of the contrast
NOTE: You can return the
settings of the options to default
values by pressing the "MENU"
and " " buttons simultaneously.
When the message "RESET"
appears on the screen, this
indicates that resetting is
completed.
13
