Summary of Contents for Microtek 729S
- Page 2 Copyright © 2005 Microtek International,Inc. Microtek® is a registered trademark of Microtek International, Inc. All other trademarks or registered trademarks are the property of their respective holders. Specifications, software and hardware bundles are subject to change without notice. Delivery of technical support services subject to change without notice. Not responsible for typographical errors.
- Page 3 CE mark for Class B ITE (Following European standard EN55022/ 1998; EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11) Radio Frequency Interference Statement Warning: This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Canadian Doc Notice For Class B Computing Devices This digital apparatus does not exceed the Class B limits for radio noise emissions...
-
Page 4: Table Of Contents
Your New LCD Monitor ... 1 Unpacking ... 1 Identifying Components ... 3 A. The LCD Monitor — Front View ... 3 B. Hot Keys ... 4 C. The LCD Monitor — Rear View ... 4 Connecting the AC Power and Video Cable ... 6 Power Management System ... -
Page 5: Your New Lcd Monitor
It is capable of displaying most standards, from 640 x 400 VGA to 1280 x 1024 SXGA. The digital controls located on the front panel allow the user to easily adjust the monitor’s display parameters, and the monitor’s small footprint gives you more room in your workspace for other peripherals. - Page 6 After unpacking your LCD monitor, make sure the following items are included in the box and are in good condition: • LCD monitor • AC/DC adapter • Power cord • Audio cable • VGA cable • User Guide If you find any item to be missing or appear to be damaged, contact your dealer immediately.
-
Page 7: Identifying Components
LCD monitor is in power-saving mode. 2. Monitor Stand 3. LCD Screen The LCD monitor screen is a 17-inch TFT 1280 x 1024 screen. 4. LCD Monitor Control Panel Refer to the next chapter for more details. -
Page 8: Hot Keys
LCD monitor directly. A small “Brightness” OSD is also displayed. 3. Volume adjust hot key “ ”: Press the button to adjust the Volume level of the LCD monitor directly. A small “Volume” OSD is also displayed. -
Page 9: The Lcd Monitor - Rear View
C. The LCD Monitor — Rear View Figure-3: LCD Monitor Rear View 1. VGA cable with 15-pin D-sub VGA connector 2. DC power jack 3. Audio jack... -
Page 10: Connecting The Ac Power And Video Cable
Connecting the AC Power and Video Cable Note: Turn off your PC and the LCD monitor before connecting your LCD monitor to the computer. Power Management System This LCD monitor complies with the VESA DPMS power management proposal. When the LCD monitor is in power-saving mode or detects an incorrect timing, the monitor screen will be blank, and the power LED indicator starts blinking. -
Page 11: The Display Controls
The Display Controls The LCD Monitor’s Control Panel : Power Switch This button lets you turn power for the LCD monitor ON or OFF . 2. Auto: Auto Adjustment hot key/Exit key This button lets you apply monitor adjustments for optimized visual settings and quality. -
Page 12: Adjusting The Monitor's Display
Adjusting the Monitor’s Display OSD Main Menu 1. Pressing the OSD Menu button causes the screen below (Figure 6) to appear. 2. Use the “M” to go to the submenu. 3. Repeat step 2 to select the changed item. 4. Press the 5. - Page 13 H Position V Position Sharpness Phase Clock Moves the LCD monitor’s display left or right on a horizontal plane. Moves the LCD monitor’s display up or down on a vertical plane. Adjusts the LCD monitor display to sharpen the image.
- Page 14 Figure-9: The Tools Submenu OSD H Position adjustment: OSD V Position adjustment: Language: OSD Timer: Reset setting: Resets all of the monitor's settings to their Volume Adjusts the volume. Moves the position of the OSD horizontally. Moves the position of OSD vertically.
-
Page 15: Tft Lcd Monitor Specifications 1
TFT LCD Monitor Specifications LCD Panel: Control Functions Power: Power switch with LED indicator On-Screen Display (OSD): Main Menu • Brightness/Contrast • Color • Management • Tools Display Area (inches): Display Colors: Video Interface: Scanning Frequency: (H/V, Hz) Power Management:... -
Page 16: Supported Timing
Supported Timing " 3 " 6 *Once a mode is optimized, there is no need to make any further adjustment as long as the VGA card remains unchanged. *Specifications are subject to change without notice. -
Page 17: Troubleshooting
PROBLEM: There is no LCD display If there is no display on the LCD, refer to the following: 1. Make sure that the power indicator on the LCD monitor is lit, that all connections are secure, and that the system is running on the correct timing.
