Manual Adjustment

Manual Adjustment allows you to adjust the monitor display
with user settings.
1. Power ON the LCD monitor and computer.
2. To perform manual adjustment of settings, follow the
procedures outlined in the "Operating Procedure" section,
and apply the procedures for settings described in the
following section.
NOTE:
• It is recommended that automatic adjustment be performed
when you set up the monitor the first time or after having
changed an aspect of the current system.
• In most cases, automatic adjustment is sufficient.
• It may not be possible to achieve correct adjustment with the
first automatic adjustment. In such a case, try performing
automatic adjustment 2 or 3 times.
• If necessary due to any of the following, manual adjustments
can be performed after automatic adjustment:
– When further fine adjustment is needed.
– When the computer's video input signals are Composite
Sync or Sync On Green. (Automatic adjustments may not
be possible.)
– When [OUT OF ADJUST] is displayed. (When the screen
displays an entirely dark image, the automatic screen
adjustment may be disabled. When performing an
automatic adjustment, be sure to either use the
Adjustment Pattern or try displaying an image that makes
the entire screen very bright.)
– Automatic adjustment may not be achieved correctly,
depending on what is displayed on the screen (i.e.
moving picture or the MS-DOS prompt).
