Summary of Contents for Microtek 997M
- Page 2 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. FCC WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 CE mark for Class B ITE (Following European standard EN55022/1998; EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11) Radio Frequency Interference Statement Warning: This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 4: Table Of Contents
Your New LCD Monitor Unpacking Identifying Components Hot Keys for Quick Adjusting of Monitor Settings Viewing Angle and Free Height adjusting Connecting the Power Connecting the Video Connecting the Stereo Speakers Power Management System The LCD Monitor’s Display Controls Adjusting the Monitor’s Display... -
Page 6: Your New Lcd Monitor
LCD Monitor and your computer do not overheat. Set up your LCD Monitor so that the panel is not facing a window where sunlight often comes in. The glare caused by sunlight reflecting off of the LCD Monitor’s screen will make it... -
Page 7: Identifying Components
LCD Monitor in the future. Identifying Components This LCD Monitor has been designed to provide easy access to all controls and peripheral ports. The illustrations below will help you in identifying the LCD Monitor’s controls and ports. - Page 8 The LCD Monitor — Front View Figure 1-1: The LCD Monitor Panel and Controls 1. LCD Screen The LCD Monitor Screen is a 19” TFT 1280 x 1024 SXGA screen. 2. Function Control Buttons / OSD Menu Button The 1 Screen Display) Menu and to select the function group.
-
Page 9: Hot Keys For Quick Adjusting Of Monitor Settings
5. Power Button Press this button to turn the Monitor on/off. 6. Monitor Stand The Monitor Stand supports the LCD Panel. Loop the VGA signal cable through the hole on the Monitor Stand. 7. Stereo Speakers You can connect your PC’s Audio-out port to the LCD Monitor’s Audio-in port and listen to your PC’s audio... - Page 10 Connect the AC adapter cable to this jack. 2. Audio Line-in Connect your PC’s line-out to this jack to listen the PC’s audio on the LCD monitor’s stereo speakers. (You can also connect your CD-ROM’s line-out to this jack.) 3. VGA Cable Connector This 15-pin D-Sub VGA connector is used to connect to your PC’s VGA card.
-
Page 11: Viewing Angle And Free Height Adjusting
Viewing Angle and Free Height Adjusting... -
Page 12: Connecting The Power
Figure 1-4: The AC Adapter 2. Connect the power connector of the adapter into the power jack of the LCD Monitor. The power jack is located at the rear of the Monitor near the USB hub connector. Please refer to Figure 1-5. -
Page 13: Connecting The Video
1. Turn off your PC and LCD Monitor. 2. Connect one end of the VGA signal cable to the PC’s D-sub VGA port and the other end to the monitor's VGA port. Please refer to Figure 1-6. 3. If your PC has a graphic card with a 24-pin DVI connector, you should connect it to the Digital 24-pin DVI signal cable. -
Page 14: Connecting The Stereo Speakers
When the LCD Monitor is in power-saving mode or detects an incorrect timing, the Monitor screen will go blank and the power LED indicator will start to blink. -
Page 15: The Lcd Monitor's Display Controls
The LCD Monitor’s Display Controls This chapter covers the LCD Monitor’s On-Screen Display (OSD). Using the OSD, you can adjust the contrast, brightness, display position, display clarity, color temperature, and speaker volume, as well as set OSD parameters. Please read this chapter carefully to get the most out of your LCD Monitor. -
Page 16: Osd Main Menu
OSD Main Menu Function Control button to access the OSD main menu, press the OSD Menu button (the first Function button on your LCD Monitor). To scroll between the OSD main menu options, use the second Function Control button on your LCD Monitor. The highlighted option is the one that is currently selected. - Page 17 Use this option to reset the H- Position, V- Use this option to change input between Use this option to exit the Monitor Control submenu. Use this option to change the position of Use this option to change the position Use this option to change the OSD display Use this option to exit the OSD Control submenu.
- Page 18 The OSD Exit option lets you close the OSD Program. Take note that the OSD will close by itself if left inactive. Use this option to select the LCD monitor’s color Use this option to make individual adjustments Use this option to automatically adjust the Use this option to reset Contrast, Brightness and Use this option to exit the Graphic Control submenu.
- Page 19 Pressing the OSD Menu button causes the following screen to appear (an example): Main menu Submenu The Monitor Control Option The Monitor Control option allows you to adjust the LCD monitor’s display characteristics. PORT-SELECT: the Monitor's VGA port and the DVI digital port. EXIT:...
- Page 20 CONTRAST: between the lightest and darkest areas of the LCD monitor’s display screen. BRIGHTNESS: the LCD monitor’s display screen. The Brightness level should be adjusted in conjunction with the Contrast item. RESET: Color parameters. EXIT: Misc Control Option...
- Page 21 Messages: 1. NO VIDEO When the monitor is ON and no Video signal is being received, the “NO VIDEO” message will be displayed. 2. Signal out of monitor’s supported range When the frequency range is out of the monitor’s specifications, or when the...
-
Page 22: Appendix A: Lcd Monitor Specifications
LCD Monitor Specifications LCD Panel Control Functions Power On-Screen Main Menu Display (OSD) Monitor Control OSD Control Graphic Control Misc. Control OSD Exit Display Area (mm) Display Colors Video Interface Analog port: VGA Compatible Analog RGB (15-pin D-Sub) Appendix A... - Page 23 Input Detection Scanning Frequency H/V, Hz (Analog mode) Scanning Frequency H/V, Hz (Digital mode) Power Management Power Consumption (ON/OFF, W) Dimensions WxHxD mm Net Weight (Approx.) Power Supply Environment Audio (Two 1-Watt speakers with amplifier) Regulatory AUTO-detection and OSD item for manual selection Meets VESA DPMS ON :46W max.
-
Page 24: Appendix B: Supported Timing
Supported Timing Item Standards Resolution NEC PC98 640x400 NEC PC98 640x400 MAC 13” mode 640x480 MAC 16” mode 832x624 MAC 17” mode 1024x768 640x350 640x400 640x480 VESA 640x480 VESA 640x480 VESA 800x600 SVGA 800x600 VESA 800x600 VESA 800x600 720x400 1024x768 VESA 1024x768 VESA... -
Page 25: Appendix C: Troubleshooting Procedures
Troubleshooting Procedures This LCD Monitor was pre-adjusted in the factory with standard VGA timing. Due to output timing differences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected. - Page 26 PROBLEM: There is no LCD Display If there is no display on the LCD, please perform the following steps: 1. Make sure that the power indicator on the LCD Monitor is lit, all connections are secure, and the system is running on the correct timing.
