CABLE SPECIFICATIONS

Fiber Cable
Bit error rate:
MULTIMODE
Fiber Optic Cable Recommended:
Optional:
SSDTF3011
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SSDTF3013
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SINGLEMODE
Fiber Optic Cable Recommended:
SSDTF3012
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SSDTF3014-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SSDTF3015-110 (long haul)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
SSDTF3022 (long haul)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Typical Maximum Cable Distance*:
*Actual distance dependent upon physical characteristics of network installation.
Coax Copper Cable
E1:
Cable Type
Gauge
Attenuation
Differential Characteristic Impedance
6
1 0
-9
62.5 / 125 µm multimode fiber
100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
850 nM
min: -14.0 dBm max: -12.0 dBm
min: -25.0 dBm max: -12.0 dBm
2 kilometers
850 nM
min: -14.0 dBm max: -12.0 dBm
min: -25.0 dBm max: -12.0 dBm
2 kilometers
9 µm singlemode fiber
1300 nM
min: -21.0 dBm max: -14.0 dBm
min: -25.0 dBm max: -14.0 dBm
8 kilometers
1300 nM
min: -21.0 dBm max: -14.0 dBm
min: -27.0 dBm max: -14.0 dBm
8 kilometers
1300 nM
min: -15.0 dBm max: -5.0 dBm
min: -27.0 dBm max: -14.0 dBm
15 kilometers
1300 nM
min: -15.0 dBm max: -5.0 dBm
min: -25.0 dBm max: -14.0 dBm
15 kilometers
RG-58
24 to 22 AWG
2 dB/100 meters @ 1.0 MHz
75 ±10%
SSDTF30xx
Set 4-Position Switch
NOTE: E1 must be selected (
LEFT SWITCH SET
Install Cable
NETWORK Switch Settings
1 2 3 4
Switch #4 DOWN
1 2 3 4
1
KEY
1
= UP
= DOWN
1
1
FIBER
1. Locate or build fiber cables that are compliant with specifications
on page 9, with male two-stranded TX to RX connectors installed at
both ends.
2. Connect cable with connector installed at TX location on media
converter to RX location on attached device.
3. Connect cable with connector installed at RX location on media
converter to TX location on attached device.
#4 DOWN) for proper operation.
Transmit All Ones onto Fiber
on Loss of Copper Carrier Detect
2
UP = Enabled
Transmit All Ones onto Copper
on Loss of Fiber Carrier Detect
2
UP = Enabled
NOT USED
2
E1 Selection
DOWN = E1
2
3
