CPSMC0200-200 / CPSMC0200-210

Troubleshooting

1. Is a media converter installed in the dual-slot chassis?
NO
• Install a slide-in-module media converter into the dual-slot chassis.
See page 2 for installation instructions.
• Proceed to step 2.
YES
• Proceed to step 2.
2. Is the power LED on the installed media converter illuminated?
NO
• Is the power adapter the proper type of voltage and cycle frequency
for the AC outlet? (See "Power Supply" on page 5.)
• Is the power adapter properly installed in the media converter and in
the grounded AC outlet?
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Are two media converters installed in the dual-slot chassis?
YES
• The dual-slot chassis can accommodate two media converters if the
total power requirement is 12 W or less (with a maximum of 6 W per
slot). If the converters exceed this limit, remove one of the
converters.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
NO
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
6
Contact Us
Technical Support
Technical support is available 24 hours a day.
United States: 800-260-1312
International: 952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, USA
telephone: 952-941-7600
toll free: 800-526-9267
fax: 952-941-2322
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: CPSMC0200-2x0 Series Dual-Slot PointSystem™ Chassis
Part Number: CPSMC0200-200, CPSMC0200-210
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the CPSMC0200-2x0 to which this declaration refers is in
conformity with the following standards.
EN 55022:1998 Class A & B; FCC Part 15 Subpart B
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
Stephen Anderson, Vice-President of Engineering
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
Declaration of Conformity
June 8, 2001
Date
