CPSMC0200-22x

Troubleshooting

1. Is a media converter installed in the dual-slot chassis?
NO
• Install a slide-in-module media converter into the dual-slot chassis. See
page 2 for installation instructions.
• Proceed to step 2.
YES
• Proceed to step 2.
2. Is the Power LED on the installed media converter illuminated?
NO
• Is the power supply the proper type of voltage and cycle frequency for the
AC outlet? (See "Power Supply DC Output" on page 5.)
• Is the power supply properly installed in the chassis and in the grounded
AC outlet?
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
YES
• Proceed to step 3.
3. Are two gigabit media converters installed in the dual-slot chassis?
YES
• The CPSMC0200-22x dual-slot chassis can accommodate only one
gigabit media converter. Remove one of the two gigabit media
converters.
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
NO
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
6
Contact Us
Technical Support
Technical support is available 24 hours a day.
United States: 800-260-1312
International: 952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, U.S.A.
telephone: 952-941-7600
toll free: 800-526-9267
fax: 952-941-2322

Declaration of Conformity

Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 U.S.A.
Model: CPSMC0200-22x Serues Dual-Slot PointSystem™ Chassis
Part Numbers: CPSMC0200-221, CPSMC0200-226
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the CPSMC0200-2x0 to which this declaration
refers is in conformity with the following standards: EN 55022:1998 Class A & B; FCC
Part 15 Subpart B
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s)
and Standard(s).
Stephen Anderson, Vice-President of Engineering
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
July 18, 2006
Date
