CABLE SPECIFICATIONS

The physical characteristics of the media cable must meet or exceed IEEE 802.3
specifications.
Fiber Cable
MULTIMODE
Fiber Optic Cable Recommended:
Optional:
Wavelength :
Attenuation:
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget
Typical Maximum Cable Distance:*
*Actual distance dependent upon physical characteristics of network installation.

Copper Cable

Category 5 twisted-pair copper wire is required. Either shielded twisted-pair
(STP) or unshielded twisted-pair (UTP) can be used. DO NOT USE FLAT OR
SILVER SATIN WIRE.
CATEGORY 5:
Gauge
Attenuation
Maximum Cable Distance:
The two active pairs in an Ethernet™ network are pins 1 & 2 and pins 3 & 6. Use
only dedicated wire pairs (such as blue/white & white/blue, orange/white &
white/orange) for the active pins.
Twisted pair connection requires two active pairs configured as straight through or
Straight Through
1
Twisted Pair #1
2
3
Twisted Pair #2
6
crossover, as shown:
RJ-45 Pin-out: Pin 1=TD+, Pin 2=TD-, Pin 3=RD+, Pin 6=RD-
62.5 / 125 µm multimode fiber
100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
850 nM
3.75 dB/ 1 kilometer @ 850 nM
min: -16.0 dBm max: -10.0 dBm
min: -29.50 dBm max: -7.2 dBm
13.5 dB
Full-duplex 300 meters @ 100 Mb/s
2 kilometers @ 10 Mb/s
Half Duplex: See page 4
24 to 22 AWG
22.0 dB /100m @ 100 MHz
100 meters
Crossover
1 1 1
Twisted Pair #1
2 2
2
3 3 3
Twisted Pair #2
6 6 6
Use the the CSETF10xx media converter to connect a 10BASE-T or
100BASE-TX terminal device and a 10BASE-FL or 100BASE-SX (half-duplex
only) hub, switch, or router:
Media
Conversion
Center
Power
1
In Use RXC
Power TX
2
In Use
RESET
RX
TX PWR
RX LNK
MCCM10
MGMT MASTER
Or use the the CSETF10xx media converter to connect a 10BASE-T or
100BASE-TX hub, switch, or router and a 10BASE-FL or 100BASE-SX terminal
device:
Media
Conversion
Center
Power
1
In Use
Power
2
In Use
RESET
TX PWR
RX LNK
MCCM10
MGMT MASTER
PWR SPD PWR SPD
FRX FLNK FRX
PWR SPD PWR SPD PWR
LKF
RXF FRX FLNK FRX LKC FLNK CRX CLNK CRX
LKC CRX CLNK CRX CLNK
TX
TX
TX
TX
RX
RX
RX
RX
CFETF100
CETTF100 CFETF110
PWR SPD PWR SPD
FRX
FRX FLNK
PWR SPD PWR SPD PWR
LKF
RXF FRX FLNK FRX FLNK LKC CRX CLNK CRX
RXC LKC CRX CLNK CRX CLNK
TX
TX
TX TX
TX
RX
RX
RX
RX
RX
CFETF100
CETTF100 CFETF110
