Page 2 END USER LICENSE AGREEMENT The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject to the terms and conditions of the End User License Agreement (“EULA”) posted at http://www.juniper.net/support/eula.html.
Page 3: Table Of Contents
Port Panel of an ACX5048 Router ........
Page 4 ACX5048 and ACX5096 Universal Access Router Chapter 4 Power System Components and Descriptions ......37 AC Power Supply for an ACX5000 Router ....... 37 DC Power Supply for an ACX5000 Router .
Page 6 Radiation and Laser Warnings ........175 Laser Safety Warnings for Juniper Networks Devices ..... . 175 Class 1 Laser Product Warning .
Page 7 Chassis Lifting Guidelines for an ACX5000 Router ..... . . 188 Installation Safety Warnings for Juniper Networks Devices ....188 Intra-Building Ports Warning .
Page 9 Figure 16: 1 U Fan Module Used in ACX5048 ......34...
Page 10 Figure 28: Port Panel ACX5048 ........
Page 11 Figure 55: Location of the Serial Number ID Label on a ACX5096 ... . 155 Figure 56: Location of the Serial Number ID Label on a ACX5048 ... . 155...
Page 13 Them ............6 Table 5: CLI Equivalents of Terms Used in Documentation for an ACX5048 Router .
Page 14 Table 30: Supported Optical Transceivers for an ACX5000 Router ... 60 Table 31: Optics being qualified for ACX5048 ......61 Table 32: Supported DAC and DAC Breakout Cables for the ACX5000 Router .
Page 15: About The Documentation
® To obtain the most current version of all Juniper Networks technical documentation, see the product documentation page on the Juniper Networks website at http://www.juniper.net/techpubs/ If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes.
Page 16: Table 1: Notice Icons
ACX5048 and ACX5096 Universal Access Router Table 1: Notice Icons Icon Meaning Description Informational note Indicates important features or instructions. Caution Indicates a situation that might result in loss of data or hardware damage. Warning Alerts you to the risk of personal injury or death.
Page 17: Documentation Feedback
We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation. You can provide feedback by using either of the following methods: Online feedback rating system—On any page at the Juniper Networks Technical Documentation site at , simply click the http://www.juniper.net/techpubs/index.html...
Page 18: Requesting Technical Support
7 days a week, 365 days a year. Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: http://www.juniper.net/customers/support/...
Page 19 About the Documentation For international or direct-dial options in countries without toll-free numbers, see http://www.juniper.net/support/requesting-support.html Copyright © 2015, Juniper Networks, Inc.
Page 21: Overview
PART 1 Overview System Overview and Architecture on page 3 Chassis Components and Descriptions on page 17 Cooling System Components and Descriptions on page 33 Power System Components and Descriptions on page 37 Copyright © 2015, Juniper Networks, Inc.
Page 23: System Overview And Architecture
Protocols and Applications Supported by the ACX Routers on page 10 ACX5000 Universal Access Router Overview The ACX5000 Universal Access Routers are Juniper Networks’ top-of-rack router solutions for data centers and campus distribution or aggregation environments. The ACX5000 router portfolio consists of high-performance fixed-configuration routers that add higher port densities, additional scalability, and improved latency to the ACX Series.
Page 24: Acx5096 Router
6 QSFP+ ports can be used as either access ports or uplink ports. The ACX5048 provides full duplex throughput of 1.44 Tbps. The ACX5048 has a 1 U form factor and is shipped with redundant fans and redundant power supplies. The router can be ordered with front-to-back airflow (air out or AFO) and with AC or DC power supplies.
Page 25: Acx5000 Router Models
The following are the ACX5000 FRUs: Power supplies Fan modules Table 4 on page 6 lists the FRUs for the ACX5000 and actions to take before removing them. Copyright © 2015, Juniper Networks, Inc.
Page 26: Understanding Hardware Redundancy Of An Acx5000 Router Components And Functionality
Do not operate the router with missing FRUs for longer than one minute. NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/csc/management/updateinstallbase.jsp Failure to do so can result in significant delays if you need replacement parts.
Page 27: Acx5000 Routers Hardware And Cli Terminology Mapping
Do not connect feed A and feed B to the same power supply input terminal. Cooling system—The 1 U ACX5048 router has five fan modules; the 2 U ACX5096 router has three fan modules. If a fan module fails and is unable to keep the ACX5000 router within the desired temperature thresholds, chassis alarms occur and the ACX5000 router can shut down.
Page 28: Acx5096 Router Hardware And Cli Terminology Mapping
ACX5048 and ACX5096 Universal Access Router Table 5: CLI Equivalents of Terms Used in Documentation for an ACX5048 Router (continued) Hardware Item (as Description (as displayed in displayed in the Value (as displayed the CLI) CLI) in the CLI) Item in Documentation Additional Information 48x10G–6x40G...
Page 29: Figure 4: Acx5096 Interface Port Mapping
ACX5000 Router” on page 33 ACX5096 Figure 4: ACX5096 Interface Port Mapping 1— Electrostatic Discharge (ESD) terminal 3— 40 Gigabit Ethernet ports (8) 2—10 Gigabit Ethernet ports (96) Related ACX5000 Universal Access Router Overview on page 3 Documentation Copyright © 2015, Juniper Networks, Inc.
Page 30: Acx5000 System Software Overview
32-gigabyte (GB) internal solid state flash drive. The same Junos OS code base that runs on an ACX5000 routers also runs on all Juniper Networks QFX and EX Series switches, and J Series, M Series, MX Series, ACX Series and T Series routers.
Page 31 12.3x51-D10 15.1X54–D20 15.1X54–D20 Traffic engineering 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 15.1X54–D20 15.1X54–D20 E-LINE 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 15.1X54–D20 15.1X54–D20 Pseudowire Emulation 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 15.1X54–D20 15.1X54–D20 Edge to Edge (PWE3 [signaled]) Copyright © 2015, Juniper Networks, Inc.
Page 32 ACX5048 and ACX5096 Universal Access Router Table 7: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 Static Ethernet PWs 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 15.1X54–D20 15.1X54–D20 Layer 2 circuits 12.2...
Page 33 Clock synchronization 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 – – Redundant clock (multiple – – – – – – – 1588 masters) Transparent clock – – – – – 15.1X54-D20 15.1X54-D20 OAM, Troubleshooting, Manageability, Lawful Intercept Copyright © 2015, Juniper Networks, Inc.
Page 34 ACX5048 and ACX5096 Universal Access Router Table 7: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 Network Time Protocol 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 15.1X54-D20 15.1X54-D20 (NTP) SNMP 12.2 12.2R2...
Page 35 12.3x51-D10 – – VP and VC Inverse multiplexing over 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 – – ATM (IMA) ATM Encapsulation AAL5 SDU (n-to-1 cell 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 – – relay) ATM Queuing Copyright © 2015, Juniper Networks, Inc.
Page 36 ACX5048 and ACX5096 Universal Access Router Table 7: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ATM service categories 12.2 12.2R2 12.2 12.2R2 12.3x51-D10 – – (CBR, nrt-VBR, UBR) to the MAP ATM service 12.2...
Page 37: Chassis Components And Descriptions
Chassis Components and Descriptions Management Panel of an ACX5000 Router on page 17 Port Panel of an ACX5048 Router on page 20 Port Panel of an ACX5096 Router on page 21 Chassis Status LEDs on an ACX5000 Router on page 23...
Page 38: Figure 6: Acx5096, Fru End 2 U Product Sku
ACX5048 and ACX5096 Universal Access Router Figure 6: ACX5096, FRU End 2 U Product SKU Figure 7: Management Panel Components on ACX5048 1— Status LEDs 4— RJ-45 console port ( 2— 5— USB port em1–SFP management Ethernet port ( Cage (socket for either 1 GbE copper SFP or fiber SFP) 3—em0–RJ-45 (1000 Base-T) management...
Page 39: Chassis Components And Descriptions
Solid green indicates that Junos OS for ACX Series is loaded on the router. ID–Identification or beacon Unlit indicates the beacon feature is not enabled. Blinking blue indicates the beacon feature is enabled. This feature is enabled using command. request chassis beacon Router product number Management Ports Copyright © 2015, Juniper Networks, Inc.
Page 40: Port Panel Of An Acx5048 Router
Connecting an ACX5000 Router to a Network for Out-of-Band Management on page 122 Port Panel of an ACX5048 Router The port panel of the ACX5048 supports up to a maximum of 72 logical 10 GbE ports when operating as a standalone router. Forty-eight physical ports(...
Page 41: Port Panel Of An Acx5096 Router
Chapter 2: Chassis Components and Descriptions Figure 9: ACX5048 Router Port Panel 1— Electrostatic Discharge (ESD) terminal 3— 40 Gigabit Ethernet ports (6) 2—10 Gigabit Ethernet ports (48) Related Access Port and Uplink Port LEDs on an ACX5000 Router on page 26...
Page 42: Channelizing Interfaces
ACX5048 and ACX5096 Universal Access Router 10 Gbps direct attach copper (DAC) cables Ports through support: 40 Gbps QSFP+ transceivers Additionally ports support: QSFP+ direct attach copper (DAC) cables QSFP+ to SFP+ direct attach copper break out (DACBO) cables QSFP+ to SFP+ fiber break out cables “Interface Specifications for SFP, SFP+, and QSFP+ Transceivers for an ACX5000...
Page 43: Chassis Status Leds On An Acx5000 Router
LEDs on an ACX5000 router, their colors and states, and the status they indicate. You can view the colors of the three LEDs remotely through the CLI by issuing the operational mode command show chassis lcd Copyright © 2015, Juniper Networks, Inc.
Page 44: Management Port Leds On An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Table 8: Chassis Status LEDs on an ACX5000 Router Name Color State Description ALM–Alarm or beacon Unlit The router is halted or there is no alarm. On steadily A major hardware fault has occurred, such as a temperature alarm or power failure, and the router has halted.
Page 45: Figure 12: Management Port Leds On An Acx5000 Router
No link is established, there is a fault, or the link is down. Green On steadily A link is established, but there is no link activity. Blinking or flickering A link is established, and there is link activity. Copyright © 2015, Juniper Networks, Inc.
Page 46: Access Port And Uplink Port Leds On An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Table 9: Management Port LEDs on an ACX5000 Router (continued) Color State Description Status Unlit Either the port speed is 10 M or the link is down. Green On steadily The port speed is 1000 M.
Page 47: Table 10: Acx5000 Access Port And Uplink Led Locations
Green On steadily A link is established, but there is no link activity. Blinking A link is established, and there is link activity. Amber Blinking The beacon is enabled on the port. Copyright © 2015, Juniper Networks, Inc.
Page 48: Table 12: Network Port Leds On Qsfp+ Ports On An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Table 11: Network Port LEDs on SFP+ Ports on an ACX5000 Router (continued) Color State Description Status Unlit The link is down. Amber Blinking The beacon function is enabled on the port. Green Blinking A 1-Gigabit Ethernet transceiver is installed in the port and the link is established.
Page 49: Fan Module Led On An Acx5000 Router
Removing a Fan Module from an ACX5000 Router on page 134 AC Power Supply LEDs on an ACX5000 Router Figure 14 on page 30 shows the location of the LEDs on the power supply. Copyright © 2015, Juniper Networks, Inc.
Page 50: Figure 14: Ac Power Supply Leds On An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Figure 14: AC Power Supply LEDs on an ACX5000 Router AC OK DC OK Fault AC OK DC OK Fault Table 14 on page 30 describes the LEDs on the AC power supplies. Table 14: AC Power Supply LEDs on an ACX5000 Router...
Page 51: Dc Power Supply Leds On An Acx5000 Router
An error has been detected in the power supply. Replace the power supply as soon as possible. To maintain proper airflow through the chassis, leave the power supply installed in the chassis until you are ready to replace it. Copyright © 2015, Juniper Networks, Inc.
Page 53: Cooling System Components And Descriptions
ACX5000 routers, each fan module slot has a fan icon next to it. Figure 16 on page 34 shows the 1 U fan module and Figure 17 on page 34 shows the 2 U fan module. Copyright © 2015, Juniper Networks, Inc.
Page 54: Figure 16: 1 U Fan Module Used In Acx5048
ACX5048 and ACX5096 Universal Access Router Figure 16: 1 U Fan Module Used in ACX5048 Figure 17: 2 U Fan Module Used in ACX5096 You remove and replace a fan module from the FRU end of the chassis. The router continues to operate for a limited period of time (30 seconds) during the replacement of the fan module without thermal shutdown.
Page 55: Cooling System Components And Descriptions
In data center deployments, position the router in such a manner that the labels AIR OUT on router components are next to the hot aisle. Figure 18: Air Out Airflow Through 1 U ACX5048 Chassis Copyright © 2015, Juniper Networks, Inc.
Page 56: Fan Module Status
ACX5048 and ACX5096 Universal Access Router Figure 19: Air Out Airflow Through 2 U ACX5096 Chassis Fan Module Status You can check the status of fan modules through the command or show system alarms by looking at the LEDs next to each fan module.
Page 57: Power System Components And Descriptions
The AC power supply in 1 U ACX5048 is 650 W; the AC power supply in the 2 U ACX5096, is 850 W. Both power supplies look identical. Be sure to use the correct power supply for...
Page 58: Figure 20: 1 U Ac Power Supply In An Acx5048
ACX5048 and ACX5096 Universal Access Router Figure 20: 1 U AC Power Supply in an ACX5048 1— Handle 3— AC appliance inlet 2— Security latch 4— Ejector lever Figure 21: 2 U AC Power Supply in an ACX5096 The power supply provides port-to-FRU airflow depending on the product SKU you purchase.
Page 59: Dc Power Supply For An Acx5000 Router
SKUs of ACX5000 routers without powering off the router or disrupting the routing function. The DC power supply in 1 U ACX5048 is 650 W with dual feeds for power resiliency. The DC power supply in the 2 U ACX5096 is 850 W with dual feeds for power resiliency. Both power supplies have a similar design and look identical.
Page 60: Figure 23: Dc Power Supply In Acx5048 Routers
ACX5048 and ACX5096 Universal Access Router Figure 23: DC Power Supply in ACX5048 Routers 1— Terminal block 3— Ejector lever 2— ESD grounding point 4— Handle Figure 24: DC Power Supply for an ACX5096 1— Terminal block 3— Ejector lever 2—...
Page 61: Power System Components And Descriptions
DC Power Specifications for an ACX5000 Router on page 55 Connecting DC Power to an ACX5000 Router on page 116 Management Panel of an ACX5000 Router on page 17 Field-Replaceable Units in an ACX5000 Router on page 5 Prevention of Electrostatic Discharge Damage Copyright © 2015, Juniper Networks, Inc.
Page 63: Site Planning, Preparation, And Specifications
PART 2 Site Planning, Preparation, and Specifications Preparation Overview on page 45 Power Specifications and Requirements on page 53 Port and Interface Specifications on page 57 Cable Specifications on page 91 Copyright © 2015, Juniper Networks, Inc.
Page 65: Preparation Overview
48 Power Measure the distance between external power sources and router installation site. Calculate the power consumption and “AC Power Specifications for an requirements. ACX5000 Router” on page 53 Rack or Cabinet Copyright © 2015, Juniper Networks, Inc.
Page 66: General Site Guidelines For An Acx Series Routers
ACX5048 and ACX5096 Universal Access Router Table 20: Site Preparation Checklist (continued) Item or Task For More Information Performed By Date Verify that your rack or cabinet meets the “Rack Requirements for an ACX5000 minimum requirements for the installation of Router”...
Page 67: Site Electrical Wiring Guidelines For An Acx Series Routers
Install the device in a secure area, so that only authorized personnel can access the device. Related General Safety Warnings for Juniper Networks Devices on page 170 Documentation General Safety Guidelines for Juniper Networks Devices on page 167 Installation Safety Warnings for Juniper Networks Devices on page 188...
Page 68: Environmental Requirements And Specifications For An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router 2 or Type 4 ports as described in GR-1089-CORE, Issue 4) and require isolation from the exposed OSP cabling. The addition of primary protectors is not sufficient protection in order to connect these interfaces metallically to OSP wiring.
Page 69: Chassis Physical Specifications For An Acx5000 Router
Rack requirements consist of: Rack type Mounting bracket hole spacing Rack size and strength Table 23 on page 50 provides the rack requirements and specifications for an ACX5000 router. Copyright © 2015, Juniper Networks, Inc.
Page 70: Cabinet Requirements For An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Table 23: Rack Requirements for an ACX5000 Router Rack Requirement Guidelines Rack type (all router Use a four-post rack that provides bracket holes or hole patterns spaced at 1 U (1.75 in. or 4.45 cm) models) increments and that meets the size and strength requirements to support the weight.
Page 71: Clearance Requirements For Airflow And Hardware Maintenance For An Acx5000
Clearance Requirements for Airflow and Hardware Maintenance for an ACX5000 Router When planning the site for installing an ACX5000 router, you must allow sufficient clearance around the installed chassis (see Figure 26 on page 52). Copyright © 2015, Juniper Networks, Inc.
Page 72: Figure 26: Clearance Requirements For Airflow And Hardware Maintenance For
ACX5048 and ACX5096 Universal Access Router Figure 26: Clearance Requirements for Airflow and Hardware Maintenance for an ACX5000 Router For the cooling system to function properly, the airflow around the chassis must be unrestricted. See “Cooling System and Airflow in an ACX5000 Router” on page 33 more information about the airflow through the chassis.
Page 73: Power Specifications And Requirements
315 W Maximum power consumption ACX5048 365 W ACX5096 470 W Related AC Power Cord Specifications for an ACX5000 Router on page 54 Documentation AC Power Supply for an ACX5000 Router on page 37 Copyright © 2015, Juniper Networks, Inc.
Page 74: Ac Power Cord Specifications For An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router General Safety Guidelines and Warnings General Electrical Safety Guidelines and Warnings AC Power Cord Specifications for an ACX5000 Router Detachable AC power cords are shipped with the chassis, if you include them as part of your order.
Page 75: Dc Power Specifications For An Acx5000 Router
315 W Maximum power ACX5048 385 W consumption ACX5096 470 W Related DC Power Supply for an ACX5000 Router on page 39 Documentation DC Power Supply LEDs on an ACX5000 Router on page 31 Copyright © 2015, Juniper Networks, Inc.
Page 77: Port And Interface Specifications
Interface Specifications for QSFP+ DAC Cables for an ACX5000 Router on page 86 USB Port Specifications for an ACX5000 Router The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port in the ACX5000 routers: RE-USB-1G-S—1-gigabyte (GB) USB flash drive...
Page 78: Console Port Connector Pinouts For An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router NOTE: USB flash drives used with the ACX5000 router must support USB 2.0 or later. Console Port Connector Pinouts for an ACX5000 Router The console port (labeled , or ) is an RS-232 serial interface that uses CONSOLE an RJ-45 connector to connect to a console management device.
Page 79: Interface Support For An Acx5000 Router
(QSFP+) ports for use as uplinks or as access ports. These 40 GbE ports support QSFP+ transceivers, QSFP+ direct-attach copper (DAC) cables, and DAC breakout cables (DACBO). The ACX5048 has 6 QSFP+ ports; the ACX5096 has 8 QSFP+ ports that can all be used as uplinks.
Page 80: Figure 27: Port Panel Acx5096
ACX5048 and ACX5096 Universal Access Router Figure 27: Port Panel ACX5096 1— Electrostatic discharge (ESD) terminal 3— QSFP+ uplink ports (8) 2—SFP+ access ports (96) Figure 28: Port Panel ACX5048 1— Electrostatic discharge (ESD) terminal 3— QSFP+ uplink ports (6) 2—SFP+ access ports (48)
Page 81: Table 31: Optics Being Qualified For Acx5048
CAUTION: If you are having a problem running a Juniper Networks device that is using a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 82: Interface Specifications For Sfp, Sfp+, And Qsfp+ Transceivers For An Acx5000 Router
. The command does not give any output for copper transceivers or transceivers not purchased from Juniper Networks. The three tables in this topic describe the optical interface support over single-mode fiber-optic (SMF) and multimode fiber-optic (MMF) cables and copper interface support...
Page 83: Table 33: Copper Interface Support And Optical Interface Support For Gigabit Ethernet Sfp Transceivers For Acx5000 Routers
Minimum launch power – Maximum launch power – Minimum receiver sensitivity – Maximum input power – DOM support Not available Fiber type – Core/cladding size – Modal bandwidth – Distance 100 m (328 ft) Copyright © 2015, Juniper Networks, Inc.
Page 84 ACX5048 and ACX5096 Universal Access Router Table 33: Copper Interface Support and Optical Interface Support for Gigabit Ethernet SFP Transceivers for ACX5000 Routers (continued) Ethernet Standard Specifications 1000BASE-SX Product SKU number -SFP-1GE-SX Rate 1000 Mbps Connector type Fiber count Dual...
Page 85 –9.5 dBm Maximum launch power –3 dBm Minimum receiver sensitivity –25 dBm Maximum input power –3 dBm DOM support Available Fiber type Core/cladding size 9/125 µm Modal bandwidth – Distance 10 km (6.2 miles) Copyright © 2015, Juniper Networks, Inc.
Page 86: Table 34: Optical Interface Support For 10-Gigabit Ethernet Sfp+ Transceivers
ACX5048 and ACX5096 Universal Access Router Table 34: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for ACX5000 Routers Ethernet Standard Specifications 10GBASE-SR Product SKU number -SFP-10GE-USR Rate 10 Gbps Connector type Fiber count Dual Transmitter 850 nm wavelength Minimum launch –7.3 dBm...
Page 87 (OM4 compatible) Modal bandwidth 160 MHz/km 200 MHz/km 400 MHz/km 500 MHz/km 1500 MHz/km Distance 26 m (85 ft) 33 m (108 ft) 66 m (216 ft) 82 m (269 ft) 300 m (984 ft) Copyright © 2015, Juniper Networks, Inc.
Page 88 ACX5048 and ACX5096 Universal Access Router Table 34: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for ACX5000 Routers (continued) Ethernet Standard Specifications 10GBASE-LR Product SKU number -SFP-10GE-LR Rate 10 Gbps Connector type Transmitter 1310 nm wavelength Minimum launch –8.2 dBm...
Page 89 –4.7 dBm power Maximum launch 4 dBm power Minimum receiver –11.3 dBm sensitivity Maximum input power –1 dBm DOM support Available Fiber type Core/cladding size 9/125 µm Modal bandwidth – Distance 40 km (24.8 miles) Copyright © 2015, Juniper Networks, Inc.
Page 90 ACX5048 and ACX5096 Universal Access Router Table 34: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for ACX5000 Routers (continued) Ethernet Standard Specifications 10GBASE-ZR Product SKU Number EX-SFP-10GE-ZR Rate 10 Gbps Connection Type Fiber count Dual Transmitter 1550 ;nm wavelength...
Page 91: Table 35: Interface Support For 40-Gigabit Ethernet Qsfp+ Transceivers For
Minimum –5.4 dBm receiver sensitivity Maximum 4 dBm input power Available support Fiber type Core/ claddi n g 50/125 µm 50/125 µm size Fiber grade Distance 100 m (325 ft) 150 m (425 ft) Copyright © 2015, Juniper Networks, Inc.
Page 92 ACX5048 and ACX5096 Universal Access Router Table 35: Interface Support for 40-Gigabit Ethernet QSFP+ Transceivers for ACX5000 Routers (continued) Ethernet Specifications Standard 40GBASE Product -QSFP-40G-ESR4 -ESR4 number Rate 40 Gbps Connector 12-ribbon multimode fiber crossover cable with female MPO connectors...
Page 93 Minimum -7.6 dBm (per lane) launch power Maximum 2.4 dBm (per lane) launch power Minimum – receiver sensitivity Available support Fiber type Core/ claddi n g 9/125 µm size Distance 10 km (6.2 miles) Copyright © 2015, Juniper Networks, Inc.
Page 94 ACX5048 and ACX5096 Universal Access Router Table 35: Interface Support for 40-Gigabit Ethernet QSFP+ Transceivers for ACX5000 Routers (continued) Ethernet Specifications Standard 40GBASE Product JNP-QSFP-40G-LX4 -LX4 Number Rate 40 Gbps (10 Gbps per lane) Connector Dual LC Fiber Dual count Lane Lane 0–1271 nm...
Page 95 Minimum -6.0 dBm (per lane) launch power Maximum 1.5 dBm (per lane) launch power Minimum – receiver sensitivity Available support Fiber type Core/ claddi n g 9/125 µm size Distance 1.4 km (.9 miles) Copyright © 2015, Juniper Networks, Inc.
Page 96 ACX5048 and ACX5096 Universal Access Router Table 35: Interface Support for 40-Gigabit Ethernet QSFP+ Transceivers for ACX5000 Routers (continued) Ethernet Specifications Standard 40GBASE Product JNP-QSFP-40GE-IR4 -IR4 Number Rate 40 Gbps (10 Gbps per lane) Connector type Fiber Dual count Lane Lane 0 through 3–1271 to 1331 nm...
Page 97: Interface Specifications For Sfp+ Dac Cables For An Acx5000 Router
Small form-factor pluggable plus (SFP+) direct attach copper (DAC) cables, also known as Twinax cables, are suitable for in-rack connections between servers. While we highly recommend using Juniper Network DAC cables, ACX5000 routers do support third-party DAC cables. If you choose to use a third-party cable, it should meet...
Page 98: Table 37: Sfp+ Passive Direct Attach Copper Cable Specifications
ACX5048 and ACX5096 Universal Access Router Table 37: SFP+ Passive Direct Attach Copper Cable Specifications Product Number Specifications QFX-SFP-DAC-1M Rate 10-Gbps full-duplex serial transmission Connector type None. SFPs are permanently attached. Supply voltage 3.3 V Power consumption (per end) 0.015 W °...
Page 99 Cable type Twinax Wire AWG 24 AWG Minimum cable bend radius 1.25 in. (3.2 cm) Cable characteristic impedance 100 ohms Crosstalk between pairs 2% maximum Time delay 4.3 nsec/m Length 5 m (16.4 ft) Copyright © 2015, Juniper Networks, Inc.
Page 100: Table 38: Sfp+ Active Direct Attach Copper Cable Specifications
ACX5048 and ACX5096 Universal Access Router Table 38: SFP+ Active Direct Attach Copper Cable Specifications Product Number Specifications QFX-SFP-DAC-1MA Rate 10-Gbps full-duplex serial transmission Connector type None. SFPs are permanently attached. Supply voltage 3.3 V Power consumption (per end) 0.627 W °...
Page 101 –40 C to 85 Cable type Twinax Wire AWG 30 AWG Minimum cable bend radius 1 in. (2.54 cm) Cable characteristic impedance 100 ohms Crosstalk between pairs 2% maximum Length 7 m (23 ft) Copyright © 2015, Juniper Networks, Inc.
Page 102: Interface Specifications For Qsfp+ Dac Breakout Cables For An Acx5000
CAUTION: If you are having a problem running a Juniper Networks device that is using a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Copyright © 2015, Juniper Networks, Inc.
Page 103: Table 39: Third-Party Qsfp+ Dac Breakout Cable Support
Chapter 7: Port and Interface Specifications Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device. Table 39: Third-Party QSFP+ DAC Breakout Cable Support...
Page 104 ACX5048 and ACX5096 Universal Access Router Table 40: QSFP+ DAC Passive Breakout Cable Specifications (continued) Product SKU Specifications QFX-QSFP-DACBO-3M Rate 40-Gbps full-duplex serial transmission Connector type None. SFPs are permanently attached. Supply voltage 3.3 V ° ° Storage temperature –40...
Page 105: Router
Interface Specifications for SFP, SFP+, and QSFP+ Transceivers for an ACX5000 Documentation Router on page 62 Interface Specifications for SFP+ DAC Cables for an ACX5000 Router on page 77 Interface Specifications for QSFP+ DAC Cables for an ACX5000 Router on page 86 Copyright © 2015, Juniper Networks, Inc.
Page 106: Interface Specifications For Qsfp+ Dac Cables For An Acx5000 Router
DAC breakout cables. Earlier releases do not support third-party breakout cables. While we highly recommend using Juniper Network DAC cables, you may use cables from a third-party vendor. If you choose to use a third-party cable, it should meet the...
Page 107: Table 43: Interface Specifications For Passive Copper Qsfp+ Dac Cables
Cable type Twinax Wire AWG 30 AWG Minimum cable bend radius 1 in. (2.54 cm) Cable characteristic impedance 100 ohms Crosstalk between pairs 1% maximum Time delay 4.3 nsec/m Length 3 m (9.9 ft) Copyright © 2015, Juniper Networks, Inc.
Page 108 ACX5048 and ACX5096 Universal Access Router Table 43: Interface Specifications for Passive Copper QSFP+ DAC Cables (continued) Product Number Specifications JNP-QSFP-DAC-5M Rate 40-Gbps full-duplex serial transmission Connector type None. SFPs are permanently attached. Supply voltage 3.3 V Power consumption (per end) 0.015 W...
Page 109: Table 44: Interface Specifications For Active Copper Qsfp+ Dac Cables
Cable type Twinax Wire AWG 30 AWG Minimum cable bend radius 0.3 in. (0.762 cm) Cable characteristic impedance 100 ohms Crosstalk between pairs 2 % maximum Time delay 4.3 nsec/m Length 7 m (22.9 ft) Copyright © 2015, Juniper Networks, Inc.
Page 110 ACX5048 and ACX5096 Universal Access Router Table 44: Interface Specifications for Active Copper QSFP+ DAC Cables (continued) Product Number Specifications JNP-QSFP-DAC-10MA Rate 40-Gbps full-duplex serial transmission Connector type None. SFPs are permanently attached. Supply voltage 3.3 V Power consumption 0.058 W °...
Page 111: Cable Specifications
Table 45 on page 91 describes the signals on each fiber. Table 46 on page 92 shows the pin to pin connections for proper polarity. Table 45: QSFP+ MPO Cable Signals Fiber Signal Tx0 (Transmit) Copyright © 2015, Juniper Networks, Inc.
Page 112: Table 46: Qsfp+ Mpo Fiber-Optic Crossover Cable Pinouts
ACX5048 and ACX5096 Universal Access Router Table 45: QSFP+ MPO Cable Signals (continued) Fiber Signal Tx1 (Transmit) Tx2 (Transmit) Tx3 (Transmit) Unused Unused Unused Unused Rx3 (Receive) Rx2 (Receive) Rx1 (Receive) Rx0 (Receive) Table 46: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts...
Page 113: Cable Specifications For Console And Management Connections For An Acx5000
This separate protective earthing terminal must be permanently connected to earth ground for installations that require a separate grounding conductor to the chassis. Copyright © 2015, Juniper Networks, Inc.
Page 114: Understanding Fiber-Optic Cable Signal Loss, Attenuation, And Dispersion In An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router WARNING: To comply with GR-1089 requirements, all intra-building copper cabling used for SFP+ and QSFP+ ports must be shielded and grounded at both ends. CAUTION: Before router installation begins, a licensed electrician must attach a cable lug to the grounding cables that you supply.
Page 115: Attenuation And Dispersion In Fiber-Optic Cable
(including those from dispersion), and a safety margin for unexpected losses. Calculating Power Budget and Power Margin for Fiber-Optic Cables Supported Platforms ACX Series M Series MX Series PTX Series T Series Copyright © 2015, Juniper Networks, Inc.
Page 116: Calculating Power Budget For Fiber-Optic Cable
ACX5048 and ACX5096 Universal Access Router Use the information in this topic and the information in Supported Network Interface Standards by Transceiver for ACX, M, MX, and T Series Routers or Supported Network Interface Standards by Transceiver for PTX Series Routers to calculate the power budget and power margin for fiber-optic cables.
Page 117: Table
(0.5 dB per connector, or 3.5 dB). The power margin (P ) is calculated as follows: – LL = 13 dB – 8 km (0.5 dB/km) – 7(0.5 dB) = 13 dB – 4 dB – 3.5 dB = 5.5 dB Copyright © 2015, Juniper Networks, Inc.
Page 118 ACX5048 and ACX5096 Universal Access Router In both examples, the calculated power margin is greater than zero, indicating that the link has sufficient power for transmission and does not exceed the maximum receiver input power. Related Understanding Fiber-Optic Cable Signal Loss, Attenuation, and Dispersion Documentation Copyright ©...
Page 119: Initial Installation And Configuration
Unpacking the Router on page 101 Installing the Router on page 103 Connecting the Router to Power on page 111 Connecting the Router to the Network on page 121 Performing Initial Configuration on page 125 Copyright © 2015, Juniper Networks, Inc.
Page 121: Unpacking The Router
Pull out the packing material holding the router in place. Verify the chassis components received: Two power supplies Fan modules: Five fan modules for ACX5048 Three fan modules for ACX5096 Save the shipping carton and packing materials in case you need to move or ship the router later.
Page 122: Table 49: Inventory Of Components Supplied With An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Table 49: Inventory of Components Supplied with an ACX5000 Router Component Quantity Chassis with five fan modules and two power supplies. The ACX5096 has three fan modules. Rear mounting blades Front mounting brackets Extension brackets...
Page 123: Installing The Router
Related Rack Requirements for an ACX5000 Router on page 49 Documentation Cabinet Requirements for an ACX5000 Router on page 50 Clearance Requirements for Airflow and Hardware Maintenance for an ACX5000 Router on page 51 Copyright © 2015, Juniper Networks, Inc.
Page 124: Mounting An Acx5000 Router In A Rack Or Cabinet
ACX5048 and ACX5096 Universal Access Router Mounting an ACX5000 Router in a Rack or Cabinet You can mount all ACX5000 router on a four post 19-in. rack or cabinet using the mounting kit provided with the device. For four post rack or cabinet installations, the mounting kit contains two front mounting rails with two matching rear mounting blades.
Page 125 Optional equipment: Grounding cable kit with bracket, lug, and three nuts with integrated washers. WARNING: The 1 U ACX5048 must be supported at all four corners. Mounting the chassis using only the front brackets will damage the chassis and can result in serious bodily injury.
Page 126: Four Post Procedure
Figure 30 on page 106 for the ACX5096 router. Figure 29: Attaching Mounting Rails to the ACX5048 Router Figure 30: Attaching Mounting Rails to the ACX5096 Router Attach the mounting rail to the router using the mounting screws (and cage nuts and washers if your rack requires them).
Page 127: Figure 31: Attach 1 U Router To Rack
Use the four mounting screws (and cage nuts and washers if your rack requires them) to attach each blade to the rack. Use eight front-mounting screws for the ACX5096. Tighten the screws. Figure 33 on page 108. Copyright © 2015, Juniper Networks, Inc.
Page 128: Two Post Procedure
ACX5048 and ACX5096 Universal Access Router Figure 33: Slide Mounting Blades into 1 U Mounting Rail 1— Rearmounting-blades 3— Router chassis 2—Side mounting-rails Ensure that the router chassis is level by verifying that all the screws on the front of the rack are aligned with the screws at the back of the rack.
Page 129 Rack-Mounting and Cabinet-Mounting Warnings Documentation Connecting AC Power to an ACX5000 Router on page 114 Connecting DC Power to an ACX5000 Router on page 116 Connecting Earth Ground to an ACX5000 Router on page 112 Copyright © 2015, Juniper Networks, Inc.
Page 131: Connecting The Router To Power
Connecting the Router to Power Connecting Earth Ground to an ACX5000 Router on page 112 Connecting AC Power to an ACX5000 Router on page 114 Connecting DC Power to an ACX5000 Router on page 116 Copyright © 2015, Juniper Networks, Inc.
Page 132: Connecting Earth Ground To An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Connecting Earth Ground to an ACX5000 Router To meet safety and electromagnetic interference (EMI) requirements and to ensure proper operation, you must connect the ACX5000 router to earth ground before you connect it to power.
Page 133: Figure 35: Connecting A Grounding Cable To A 1 U Acx5048
Figure 36 on page 113. Figure 35: Connecting a Grounding Cable to a 1 U ACX5048 Figure 36: Connecting a Grounding Cable to the 2 U ACX5096 Connect one end of the grounding cable to a proper earth ground, such as the rack in which the router is mounted.
Page 134: Connecting Ac Power To An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Connecting AC Power to an ACX5000 Router The power supply in an ACX5000 router is a hot-removable and hot-insertable field-replaceable unit (FRU). You can remove and replace it without powering off the router or disrupting routing functions.
Page 135: Figure 37: Connecting An Ac Power Cord To An Ac Power Supply In A 1 U
NOTE: The router powers on as soon as power is provided to the power supply. There is no power router on the device. Insert the power cord plug into an AC power source outlet. Copyright © 2015, Juniper Networks, Inc.
Page 136: Connecting Dc Power To An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router If the AC power source outlet has a power router, set it to the ON ( ) position. Verify that the AC and DC LEDs on each power supply are lit green. If the amber fault LED is lit, remove power from the power supply, and replace the power supply (see “Removing a Power Supply from an ACX5000 Router”...
Page 137 Ensure that the input circuit breaker is open so that the voltage across the DC power source cable leads is 0 V and that the cable leads do not become active while you are connecting DC power. Copyright © 2015, Juniper Networks, Inc.
Page 138 ACX5048 and ACX5096 Universal Access Router NOTE: The V+ terminals are referred to as +RTN, and V– terminals are referred to as –48 V in DC Power Wiring Sequence Warning and DC Power Electrical Safety Guidelines. Ensure that the power supplies are fully inserted in the chassis.
Page 139: Figure 39: Dc Power Supply Faceplate For A Acx5000 Router
Do not connect the terminals to different sources. Figure 40: Securing Ring Lugs to the Terminals on the ACX5000 DC Power Supply Replace the terminal block cover. Close the input circuit breaker. Copyright © 2015, Juniper Networks, Inc.
Page 140 ACX5048 and ACX5096 Universal Access Router NOTE: The switch powers on as soon as power is provided to the power supply. There is no power switch on the device. Verify that the LEDs on the power supply are lit green and are on steadily.
Page 141: Connecting The Router To The Network
Connect the other end of the Ethernet cable into the console server (see Figure 41 on page 121) or management console (see Figure 42 on page 122). Figure 41: Connecting the ACX Router to a Management Console Through a Console Server Copyright © 2015, Juniper Networks, Inc.
Page 142: Connecting An Acx5000 Router To A Network For Out-Of-Band
ACX5048 and ACX5096 Universal Access Router Figure 42: Connecting the ACX Router Directly to a Management Console Related Console Port Connector Pinouts for an ACX5000 Router on page 58 Documentation Connecting an ACX5000 Router to a Network for Out-of-Band Management You can monitor and manage the ACX5000 router using a dedicated management channel.
Page 143: Figure 43: Connecting A Acx5000 Router To A Network For Out-Of-Band
Management Related Management Panel of an ACX5000 Router on page 17 Documentation Management Port Connector Pinouts for an ACX5000 Router on page 58 Connecting an ACX5000 Router to a Management Console on page 121 Copyright © 2015, Juniper Networks, Inc.
Page 145: Performing Initial Configuration
Start the CLI. root@% cli Enter configuration mode. root> configure Add a password to the root administration user account. [edit] root@# set system root-authentication plain-text-password New password: password Retype new password: password Copyright © 2015, Juniper Networks, Inc.
Page 146 ACX5048 and ACX5096 Universal Access Router (Optional) Configure the name of the router. If the name includes spaces, enclose the name in quotation marks (“ ”). [edit] root@# set system host-name host-name Configure the default gateway. [edit] root@# set routing-options static route default next-hop address Configure the IP address and prefix length for the router management interface.
Page 147: Installing, Maintaining, And Replacing Components
Installing, Maintaining, and Replacing Components Removing the Router on page 129 Replacing Cooling System Component on page 133 Replacing Power Supply on page 137 Replacing Transceiver on page 141 Maintaining and Replacing Fiber-Optic Cable on page 145 Copyright © 2015, Juniper Networks, Inc.
Page 149: Removing The Router
A message appears on the console, confirming that the operating system has halted. You see the following output (or something similar, depending on the hardware being shut down) after entering the command: Copyright © 2015, Juniper Networks, Inc.
Page 150 ACX5048 and ACX5096 Universal Access Router request system halt warning: This command will halt all the members. If planning to halt only one member use the member option Halt the system ? [yes,no] (no) yes Shutdown at Thu Jul 30 21:20:07 2015.
Page 151: Removing An Acx5000 Router From A Rack Or Cabinet
When you remove multiple devices from a rack, remove the device in the top of the rack first and proceed to remove the rest of the devices from top to bottom. Before removing an ACX5000 router from a rack: Copyright © 2015, Juniper Networks, Inc.
Page 152 ACX5048 and ACX5096 Universal Access Router Ensure that the rack is stable and secured to the building. Ensure that there is enough space to place the removed ACX5000 router in its new location and along the path to the new location.
Page 153: Replacing Cooling System Component
Compare the router product SKU with the airflow marking on the handle to ensure that you are installing a fan module with the same airflow direction as the chassis. The fan Copyright © 2015, Juniper Networks, Inc.
Page 154: Removing A Fan Module From An Acx5000 Router
Airflow in an ACX5000 Router” on page 33 for more information. Using a Phillips screwdriver, turn the locking screw until it is tight. Figure 44: Installing a Fan Module in a 1 U ACX5048 Figure 45: Installing a Fan Module in a 2 U ACX5096 Related...
Page 155: Figure 46: Removing A Fan Module From A 1 U Acx5048
Place the fan module in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Figure 46: Removing a Fan Module from a 1 U ACX5048 Figure 47: Removing a Fan Module from a 2 U ACX5096...
Page 156 ACX5048 and ACX5096 Universal Access Router NOTE: When a fan module is removed, the CLI message Fan/Blower is Absent is logged in the system log, and the system raises a minor alarm. Related Cooling System and Airflow in an ACX5000 Router on page 33...
Page 157: Replacing Power Supply
Using both hands, place the power supply in the power supply slot on the FRU panel of the router and slide it in until it is fully seated and the locking lever slides into place. Copyright © 2015, Juniper Networks, Inc.
Page 158: Removing A Power Supply From An Acx5000 Router
Each power supply must be connected to a dedicated power source outlet. NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/csc/management/updateinstallbase.jsp Failure to do so can result in significant delays if you need replacement parts.
Page 159 Replace the screws on the terminals and tighten them. Slide the locking lever toward the handle until it stops. Grasp the power supply handle and pull firmly to slide the power supply halfway out of the chassis. Copyright © 2015, Juniper Networks, Inc.
Page 160: Figure 50: Removing Power Supply From An Acx5048
Place the power supply in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Figure 50: Removing Power Supply from an ACX5048 Figure 51: Removing Power Supply from an ACX5096 Related Installing a Power Supply in an ACX5000 Router on page 137...
Page 161: Replacing Transceiver
WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable. The rubber safety cap keeps the port clean and prevents accidental exposure to laser light. Copyright © 2015, Juniper Networks, Inc.
Page 162: Installing A Transceiver In An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router CAUTION: Do not bend fiber-optic cables beyond their minimum bend radius. Bending the cables beyond their minimum bend radius can damage the cables and cause problems that are difficult to diagnose. Remove the cable connected to the transceiver (see “Disconnecting a Fiber-Optic...
Page 163 Remove the rubber safety cap when you are ready to connect the cable to the transceiver. WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. Copyright © 2015, Juniper Networks, Inc.
Page 164: Figure 52: Installing An Sfp Transceiver
ACX5048 and ACX5096 Universal Access Router Figure 52: Installing an SFP Transceiver Figure 53: Installing a QSFP+ Transceiver—Vertical Orientation QSFP transceiver Figure 54: Installing a QSFP+ Transceiver—Horizontal Orientation Related Removing a Transceiver from an ACX5000 Router on page 141 Documentation Connecting a Fiber-Optic Cable to an ACX5000 Router on page 146 Copyright ©...
Page 165: Maintaining And Replacing Fiber-Optic Cable
WARNING: Do not stare into the laser beam or view it directly with optical instruments even if the interface has been disabled. Carefully unplug the fiber-optic cable connector from the transceiver. Copyright © 2015, Juniper Networks, Inc.
Page 166: Connecting A Fiber-Optic Cable To An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Cover the transceiver with a rubber safety cap. WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable. The rubber safety cap keeps the port clean and prevents accidental exposure to laser light.
Page 167: Maintaining Fiber-Optic Cables In An Acx5000 Router
Fiber Cleaner. Follow the directions in the cleaning kit you use. Related Connecting a Fiber-Optic Cable to an ACX5000 Router on page 146 Documentation Disconnecting a Fiber-Optic Cable from an ACX5000 Router on page 145 Copyright © 2015, Juniper Networks, Inc.
Page 169: Contacting Customer Support And Returning The Chassis Or Components
PART 5 Contacting Customer Support and Returning the Chassis or Components Contacting Customer Support on page 151 Locating Component Serial Numbers on page 153 Packing and Returning Components on page 157 Copyright © 2015, Juniper Networks, Inc.
Page 171: Contacting Customer Support
M Series MX Series PTX Series T Series You can contact Juniper Networks Technical Assistance Center (JTAC) 24 hours a day, 7 days a week in one of the following ways: On the Web, using the Case Manager link at: http://www.juniper.net/support/...
Page 173: Locating Component Serial Numbers
Locating the Serial Number on an ACX5000 Router or Component If you are returning a router or component to Juniper Networks for repair or replacement, you must locate the serial number of the router or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization (RMA).
Page 174: Locating The Chassis Serial Number Id Label On An Acx5000 Router
ACX5048 and ACX5096 Universal Access Router Xcvr 0 REV 01 740-011613 PD63CUT SFP-SX Xcvr 9 REV 01 740-021308 ARS17R5 SFP+-10G-SR Xcvr 12 REV 01 740-011782 P92080R SFP-SX Xcvr 14 REV 01 740-031851 AM1229SY9ZX SFP-SX Xcvr 20 REV 01 740-031851 PN340SM...
Page 175: Locating The Serial Number Id Labels On Fru Components
Chapter 20: Locating Component Serial Numbers Figure 55: Location of the Serial Number ID Label on a ACX5096 Figure 56: Location of the Serial Number ID Label on a ACX5048 Locating the Serial Number ID Labels on FRU Components The power supplies, fan module, and expansion modules installed in ACX5000 routers are field-replaceable units (FRUs).
Page 177: Packing And Returning Components
Returning an ACX5000 Router or Component for Repair or Replacement on page 158 Packing an ACX5000 Router or Component for Shipping If you are returning an ACX5000 router or component to Juniper Networks for repair or replacement, pack the item as described in this topic.
Page 178: Packing An Acx5000 Router Components For Shipping
Documentation Returning an ACX5000 Router or Component for Repair or Replacement If you need to return an ACX5000 router or component to Juniper Networks for repair or replacement, follow this procedure: Determine the serial number of the component. For instructions, see “Locating the...
Page 179 Chapter 21: Packing and Returning Components NOTE: Do not return any component to Juniper Networks unless you have first obtained an RMA number. Juniper Networks reserves the right to refuse shipments that do not have an RMA. Refused shipments are returned to the customer through collect freight.
Page 183: Alarm Messages
System alarm—Predefined alarm that might be triggered by a missing rescue configuration, failure to install a license for a licensed software feature, or high disk usage. Copyright © 2015, Juniper Networks, Inc.
Page 184: Acx5000 Router Interface Alarm Messages
ACX5048 and ACX5096 Universal Access Router Related Interface Alarm Messages Documentation show chassis alarms show system alarms ACX5000 Router Interface Alarm Messages Interface alarms are alarms that you configure to alert you when an interface is down. To configure an interface link-down condition to trigger a red or yellow alarm, or to...
Page 185: Safety And Compliance Information
Fire Safety Requirements on page 173 Radiation and Laser Warnings on page 175 Installation and Maintenance Safety Information on page 183 Power and Electrical Safety Information on page 195 Agency Approvals and Compliance Statements on page 209 Copyright © 2015, Juniper Networks, Inc.
Page 187: General Safety Guidelines And Warnings
CHAPTER 23 General Safety Guidelines and Warnings General Safety Guidelines for Juniper Networks Devices on page 167 Definition of Safety Warning Levels on page 168 General Safety Warnings for Juniper Networks Devices on page 170 Warning Statement for Norway and Sweden on page 172...
Page 188: Definition Of Safety Warning Levels
Some parts of the router might become hot. The following label provides the warning of the hot surfaces on the router: Related General Safety Warnings for Juniper Networks Devices on page 170 Documentation Definition of Safety Warning Levels Supported Platforms...
Page 189 Documentation Installation Safety Warnings for Juniper Networks Devices on page 188 Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 183 General Electrical Safety Warnings for Juniper Networks Devices on page 195 DC Power Electrical Safety Warnings for Juniper Networks Devices...
Page 190: General Safety Warnings For Juniper Networks Devices
ACX5048 and ACX5096 Universal Access Router General Safety Warnings for Juniper Networks Devices Supported Platforms ACX Series JCS 1200 M Series MX Series PTX Series T Series Qualified Personnel Warning on page 170 Restricted Access Area Warning on page 170...
Page 191 Varning! Denna enhet är avsedd för installation i områden med begränsat tillträde. Ett område med begränsat tillträde får endast tillträdas av servicepersonal med ett speciellt verktyg, lås och nyckel, eller annan Copyright © 2015, Juniper Networks, Inc.
Page 192: Warning Statement For Norway And Sweden
Installation Safety Warnings for Juniper Networks Devices on page 188 Documentation Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 183 General Electrical Safety Warnings for Juniper Networks Devices on page 195 DC Power Electrical Safety Warnings for Juniper Networks Devices...
Page 193: Fire Safety Requirements
Establish procedures for protecting people in a fire emergency, provide safety training, and properly provision fire-control equipment and fire extinguishers. In addition, establish procedures to protect your equipment in a fire emergency. Juniper Networks products should be installed in an environment suitable for electronic equipment.
Page 194 To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks device. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 195: Radiation And Laser Warnings
CHAPTER 25 Radiation and Laser Warnings Laser Safety Warnings for Juniper Networks Devices on page 175 Laser and LED Safety Guidelines and Warnings for the ACX Router on page 178 Laser Safety Warnings for Juniper Networks Devices Supported Platforms ACX Series...
Page 196: Class 1 Led Product Warning
ACX5048 and ACX5096 Universal Access Router Class 1 LED Product Warning WARNING: Class 1 LED product. Waarschuwing Klasse 1 LED-product. Varoitus Luokan 1 valodiodituote. Attention Alarme de produit LED Class I. Warnung Class 1 LED-Produktwarnung. Avvertenza Avvertenza prodotto LED di Classe 1.
Page 197: Radiation From Open Port Apertures Warning
öppningar. Related General Safety Guidelines for Juniper Networks Devices on page 167 Documentation General Safety Warnings for Juniper Networks Devices on page 170...
Page 198: Laser And Led Safety Guidelines And Warnings For The Acx Router
ACX5048 and ACX5096 Universal Access Router Installation Safety Warnings for Juniper Networks Devices on page 188 Laser and LED Safety Guidelines and Warnings for the ACX Router ACX5000 routers are equipped with laser transmitters: SFP and SFP+ transceivers are classified as Class 1 Laser Products (complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice 50, dated July...
Page 199: Class 1M Laser Radiation Warning
Aviso Produto laser de classe 1. ¡Atención! Producto láser Clase I. Varning! Laserprodukt av klass 1. Class 1 LED Product Warning WARNING: Class 1 LED product. Waarschuwing Klasse 1 LED-product. Varoitus Luokan 1 valodiodituote. Copyright © 2015, Juniper Networks, Inc.
Page 200: Laser Beam Warning
ACX5048 and ACX5096 Universal Access Router Attention Alarme de produit LED Class I. Warnung Class 1 LED-Produktwarnung. Avvertenza Avvertenza prodotto LED di Classe 1. Advarsel LED-produkt i klasse 1. Aviso Produto de classe 1 com LED. ¡Atención! Aviso sobre producto LED de Clase 1.
Page 201: Unterminated Fiber-Optic Cable Warning
Aviso Radiação laser invisível pode ser emitida pela ponta de um conector ou cabo de fibra não terminado. Não olhe fixa ou diretamente para o feixe ou com instrumentos ópticos. Visualizar a emissão do laser com certos Copyright © 2015, Juniper Networks, Inc.
Page 202 ACX5048 and ACX5096 Universal Access Router instrumentos ópticos (por exemplo, lupas, lentes de aumento ou microscópios) a uma distância de 100 mm pode causar riscos à visão. ¡Atención! El extremo de un cable o conector de fibra sin terminación puede emitir radiación láser invisible.
Page 203: Installation And Maintenance Safety Information
CHAPTER 26 Installation and Maintenance Safety Information Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 183 Chassis Lifting Guidelines for an ACX5000 Router on page 188 Installation Safety Warnings for Juniper Networks Devices on page 188 Maintenance and Operational Safety Warnings for Juniper Networks Devices...
Page 204: Jewelry Removal Warning
ACX5048 and ACX5096 Universal Access Router recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.
Page 205: Lightning Activity Warning
Do not work on the system or connect or disconnect cables during periods of lightning activity. Waarschuwing Tijdens onweer dat gepaard gaat met bliksem, dient u niet aan het systeem te werken of kabels aan te sluiten of te ontkoppelen. Copyright © 2015, Juniper Networks, Inc.
Page 206: Operating Temperature Warning
ACX5048 and ACX5096 Universal Access Router Varoitus Älä työskentele järjestelmän parissa äläkä yhdistä tai irrota kaapeleita ukkosilmalla. Attention Ne pas travailler sur le système ni brancher ou débrancher les câbles pendant un orage. Warnung Arbeiten Sie nicht am System und schließen Sie keine Kabel an bzw.
Page 207: Product Disposal Warning
à toutes les lois et réglementations en vigueur. Warnung Dieses Produkt muß den geltenden Gesetzen und Vorschriften entsprechend entsorgt werden. Avvertenza L'eliminazione finale di questo prodotto deve essere eseguita osservando le normative italiane vigenti in materia Copyright © 2015, Juniper Networks, Inc.
Page 208: Chassis Lifting Guidelines For An Acx5000 Router
General Safety Warnings for Juniper Networks Devices on page 170 Chassis Lifting Guidelines for an ACX5000 Router The weight of a 1 U fully loaded ACX5048 chassis is approximately 21.8 lb (9.9 kg); the 2 U ACX5096 SKU is approximately 32.5 lbs (14.74 kg). Observe the following guidelines...
Page 209: Intra-Building Ports Warning
Varning! Läs installationsanvisningarna innan du kopplar systemet till dess strömförsörjningsenhet. Rack-Mounting Requirements and Warnings Ensure that the equipment rack into which the chassis is installed is evenly and securely supported, to avoid the hazardous condition that could result from uneven mechanical loading. Copyright © 2015, Juniper Networks, Inc.
Page 210 ACX5048 and ACX5096 Universal Access Router WARNING: To prevent bodily injury when mounting or servicing the chassis in a rack, take the following precautions to ensure that the system remains stable. The following directives help maintain your safety: The chassis must be installed into a rack that is secured to the building structure.
Page 211 Advarsel Unngå fysiske skader under montering eller reparasjonsarbeid på denne enheten når den befinner seg i et kabinett. Vær nøye med at systemet er stabilt. Følgende retningslinjer er gitt for å verne om sikkerheten: Copyright © 2015, Juniper Networks, Inc.
Page 212 ACX5048 and ACX5096 Universal Access Router Router må installeres i et stativ som er forankret til bygningsstrukturen. Denne enheten bør monteres nederst i kabinettet hvis dette er den eneste enheten i kabinettet. Ved montering av denne enheten i et kabinett som er delvis fylt, skal kabinettet lastes fra bunnen og opp med den tyngste komponenten nederst i kabinettet.
Page 213: Ramp Warning
Related General Safety Guidelines for Juniper Networks Devices on page 167 Documentation General Safety Warnings for Juniper Networks Devices on page 170 Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 183 Copyright © 2015, Juniper Networks, Inc.
Page 215: Power And Electrical Safety Information
CHAPTER 27 Power and Electrical Safety Information General Electrical Safety Warnings for Juniper Networks Devices on page 195 Preventing Electrostatic Discharge Damage to an ACX5000 Router on page 199 ACX5000 AC Power Electrical Safety Guidelines and Warnings on page 200...
Page 216: Grounding Requirements And Warning
ACX5048 and ACX5096 Universal Access Router Advarsel Dette utstyret skal jordes. Forviss deg om vertsterminalen er jordet ved normalt bruk. Aviso Este equipamento deverá estar ligado à terra. Certifique-se que o host se encontra ligado à terra durante a sua utilização normal.
Page 217: Midplane Energy Hazard Warning
Varning! Denna enhet har mer än en strömförsörjningsanslutning; alla anslutningar måste vara helt avlägsnade innan strömtillförseln till enheten är fullständigt bruten. Copyright © 2015, Juniper Networks, Inc.
Page 218: Power Disconnection Warning
Varning! Innan du arbetar med ett chassi eller nära strömförsörjningsenheter skall du för växelströmsenheter dra ur nätsladden och för likströmsenheter bryta strömmen vid överspänningsskyddet. Related DC Power Electrical Safety Warnings for Juniper Networks Devices Documentation Copyright © 2015, Juniper Networks, Inc.
Page 219: Preventing Electrostatic Discharge Damage To An Acx5000 Router
199). If you are returning a component, place it in an antistatic bag before packing it. Figure 57: Placing a Component into an Antistatic Bag CAUTION ELECTROSTATIC SENSITIVE DEVICES DO NOT OPEN OR HANDLE EXCEPT AT A STATIC-FREE WORKSTATION Copyright © 2015, Juniper Networks, Inc.
Page 220: Acx5000 Ac Power Electrical Safety Guidelines And Warnings
ACX5048 and ACX5096 Universal Access Router CAUTION: ANSI/TIA/EIA-568 cables such as Category 5e and Category 6 can get electrostatically charged. To dissipate this charge, always ground the cables to a suitable and safe earth ground before connecting them to the system.
Page 221: Acx5000 Dc Power Electrical Safety Guidelines And Warnings
Varning! Innan du arbetar med ett chassi eller nära strömförsörjningsenheter skall du för växelströmsenheter dra ur nätsladden. ACX5000 DC Power Electrical Safety Guidelines and Warnings The following electrical safety guidelines apply to a DC-powered router: Copyright © 2015, Juniper Networks, Inc.
Page 222 ACX5048 and ACX5096 Universal Access Router A DC-powered device is equipped with a DC terminal block that is rated for the power requirements of a maximally configured device. NOTE: To supply sufficient power, terminate the DC input wiring on a facility DC source that is capable of supplying: Minimum of 7 A at –48 VDC for ACX5000 router...
Page 224 ACX5048 and ACX5096 Universal Access Router Varning! Innan du utför någon av följande procedurer måste du kontrollera att strömförsörjningen till likströmskretsen är bruten. Kontrollera att all strömförsörjning är BRUTEN genom att slå AV det överspänningsskydd som skyddar likströmskretsen och tejpa fast överspänningsskyddets omkopplare i FRÅN-läget.
Page 225 é –48 V a –48 V, +RTN a +RTN, moeu então para moer. Anote que o fio à terra deve sempre ser conectado primeiramente e desconectado por último. Anote que o fio Copyright © 2015, Juniper Networks, Inc.
Page 226 ACX5048 and ACX5096 Universal Access Router à terra deve sempre ser conectado primeiramente e desconectado por último. Varning! Korrekt kopplingssekvens ar jord till jord, +RTN till +RTN, –48 V till –48 V. Korrekt kopplas kopplingssekvens ar –48 V till –48 V, +RTN till +RTN, jord till jord.
Page 227 Varning! När flertrådiga ledningar krävs måste godkända ledningskontakter användas, t.ex. kabelsko av sluten eller öppen typ med uppåtvänd tapp. Storleken på dessa kontakter måste vara avpassad till ledningarna och måste kunna hålla både isoleringen och ledaren fastklämda. Copyright © 2015, Juniper Networks, Inc.
Page 229: Agency Approvals And Compliance Statements
Industry Canada ICES 003, Class A VCCI Regulations for Voluntary Control Measures of Radio Interference Generated by Information Technology Equipment, (Class A). EN 300 386, Class A EN 61000-3-2 Power Line Harmonics EN 61000-3-3 Voltage Fluctuations and Flicker Copyright © 2015, Juniper Networks, Inc.
Page 230: Compliance Statements For Emc Requirements For The Acx5000 Router
ACX5048 and ACX5096 Universal Access Router EN 55024 CISPR 24 Related Compliance Statements for EMC Requirements for the ACX5000 Router on page 210 Documentation Compliance Statements for EMC Requirements for the ACX5000 Router This topic describes the EMC requirements for the ACX5000 router for:...
Page 231: European Community
The preceding translates as follows: This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except for home. Copyright © 2015, Juniper Networks, Inc.
Page 232: United States
ACX5048 and ACX5096 Universal Access Router United States The router has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
