- Page 1 SDI Converter User Manual Model : SDI01A-12G 12G-SDI to HDMI 2.0 Converter with Audio Embedded/Extractor Smart Cabling & Transmission Corp. V1.0...
- Page 2 SDI01A-12G Introduction SDI01A-12G is a 12G-SDI to HDMI 2.0 converter that can allows you to monitor 12G SDI video using a cost-effective HDMI display. The new converter has a built-in SDI loop-out port to send the input SDI signal to an extra SDI device.
- Page 3 SDI01A-12G Step by step installation Connect 12G-SDI source to SDI01A-12G by 12G RG6U cable (BELDEN 4694 or higher). Connect 4K 6G HDMI monitor to SDI01A-12G by HDMI 2.0 premium cable. Connect 12G-SDI monitor to SDI01A-12G by 12G RG6U cable (BELDEN 4694 or higher).
-
Page 4: Led Indication
User Manual SDI01A-12G System setting HDMI audio mapping Mechanical Dip Switch Select audio interface Select HDMI resolution HDCP On / off LED Indication Front Panel LED Function Blink Green ON Power Power Good Green SIGNAL SDI Signal Indicator Signal Locked... -
Page 5: Dip Switch Settings
User Manual SDI01A-12G Dip Switch Settings Function ↑ OFF ↓ ON Video Input Select Coaxial Input Optical Input Audio Mode Audio Extractor Audio Embedder 4↑ 3↑ = XLR 4↑ 3↓ = RCA Audio Select 4↓ 3↑ = MIC 4↓ 3↓ = AES 6↑... - Page 6 User Manual SDI01A-12G SDI Resolution and Frame Rate SDI Resolution SDI Frame Rate SDI Sampling SDI Audio 4096x2160 60p, 59.94p, 50p, 48p, 47.95p, 30p, 29.97p, 25p, 24p, 23.98p 3840x2160 60p, 59.94p, 50p, 48p, 47.95p, 30p, 29.97p, 25p, 24p, 23.98p 2048x1080 60p, 60i, 59.94p, 59.94i, 50p, 50i,...
-
Page 7: Troubleshooting
User Manual SDI01A-12G Trouble Shooting We strongly recommend using high quality 75Ω coaxial cables, bad quality of cable may affect the connection stability and transmission distance. SD-SDI (480i & 576i) in the SMPTE 292 standard 270M is not supported. Any change of HDCP settings must reboot to take effect. -
Page 8: Specification
User Manual SDI01A-12G Specification ITEM NO. SDI01A-12G Support SMPTE 2082-10 Mode 1 (12G-SDI) SMPTE 2081-10 Mode 2 (6G-SDI) SMPTE 425-1 3GA & 3GB (3G-SDI) Compliance SMPTE 425-1 3GB-DS (3G-SDI) SMPTE 292 (1.5G-SDI) HDMI 2.0 HDCP 2.2 Max. Video Resolution 12G-SDI, 4096x2160@60Hz HDMI...
