Firmware Update Manual

Item No.

SDI01A-12G

Firmware Type:

WORKING

Notice

Update

Step 1

Process

Step 2 Install CP210x_VCP USB to UART driver depends on your systems version.

Step 3 Connect SDI01A-12G as below diagram

P (+886) 2 2218-6886 F (+886)2 2218-7989 E service@sct.com.tw

Required equipment list as below:

PC *1

DC 12V / 1.5A adaptor *1

Install 12G-SDI Installer for firmware update tool.

USB to Micro USB Cable *1

SDI01A-12G * 1

10F, No. 493, Chung-Cheng Rd., Hsin Tien Dist., New Taipei City 231, Taiwan

Table of Contents

Need help?

Do you have a question about the SDI01A-12G and is the answer not in the manual?

Page 1 Step 2 Install CP210x_VCP USB to UART driver depends on your systems version. Install 12G-SDI Installer for firmware update tool. Step 3 Connect SDI01A-12G as below diagram P (+886) 2 2218-6886 F (+886)2 2218-7989 E service@sct.com.tw 10F, No. 493, Chung-Cheng Rd., Hsin Tien Dist., New Taipei City 231, Taiwan...
Page 2 Notice Update Step 4 Turn off power of SDI01A-12G and connect to PC by USB to Micro USB Process Cable Step 5 Press and hold 『FW/UPDATE』button and power on, till『READY』LED lit(around 2 seconds after) then release button Step 6 Run『...
Page 3 Notice Number of USB port will different depends on PC ※ Update Step 7 Update program will detect USB port number then click 『Browse』 to Process select firmware file 『SDI01-12G_Firmware_WORKING_53172102.bin』 then click『Open』 P (+886) 2 2218-6886 F (+886)2 2218-7989 E service@sct.com.tw 10F, No.
Page 4 Notice Do not remove USB cable/power, or close update program to avoid ※ product damaged. Update Step 8 File name and path and firmware version will be update, click 『Update』 Process to start. Step 9 It will show『Update success』after finished, click OK to close the update tool P (+886) 2 2218-6886 F (+886)2 2218-7989 E service@sct.com.tw 10F, No.
