compact piezo LeD
Disconnect the handpiece from the
relative cord;
CAUTION: Do not try to unscrew or
turn the connector when disconnecting
the handpiece.
the connector can be damaged.
Unscrew the nose cone from the
handpiece.
NOTE: the nose cone has a light pipe.
if the nose cone is unscrewed, the light
pipe will no longer be held in place
and may slide and be disconnected. Be
careful not to lose the light pipe.
NOTE: On the "Front cone for LED
handpiece" (cod. 03020158) of the
MANIPOLO ABLATORE LED (LED SCALER
HANDPIECE - cod. 03120142), the metal
ring cannot be separated from the
plastic cone.
Remove the light pipe from the nose
cone.
16
2
3
4
5
