The analysis sequence describes what is taking place throughout the instrument during an analysis.
The instrument schematic, shown below, will be used to show the state of the system components
during the various phases of an analysis.
Gas
inlet
ports
The state of a valve is indicated by the icon color.
Green = open
White = closed
(when in Manual Mode, yellow = closed)
Aug 2013

3. THE ANALYSIS SEQUENCE

Po transducer
Po tube
Manifold transducer
Elevator
Analysis Sequence
Temperature
readings
Sample
transducers
Sample tubes
3-1
