The analysis sequence describes what is taking place throughout the instrument during an analysis.The
instrument schematic, shown below, will be used to show the state of the system components during the
various phases of an analysis.
10 mmHg transducer (Displays only if the Krypton option is installed.)
Gas
inlet
ports
Po tube
The state of a valve is indicated by the icon color.
Jul 09

3. THE ANALYSIS SEQUENCE

Green = open
White = closed
(when in Manual Mode, yellow = closed)
Analysis Sequence
1000 mmHg
transducer
Temperature
Sample
transducers
Sample tubes
Elevator
