Jøtul GF 370 DV MV
Direct Vent Gas Stove
Pilot on Demand Ignition
Installation and
Operation Instructions
Certified to ANSI Z21.88-2019 • CSA 2.33-2019 and
CAN/CGA 2.17-M-17.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of
life.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
– In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall be
installed in the same room as the appliance.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or mobile
home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate. A conversion kit is supplied
with the appliance.
DANGER
!
!
A barrier designed to reduce the burn hazard
from the hot viewing glass is provided with this
appliance and must be installed for the protection
of children and other at-risk individuals.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jøtul GF 370 DV MV
Summary of Contents for Jøtul GF 370 DV MV
- Page 1 – Installation and service must be performed by a qualified installer, service agency or the gas supplier. – In the Commonwealth of Massachusetts, Jøtul GF 370 DV MV a carbon monoxide (CO) detector shall be installed in the same room as the appliance. Direct Vent Gas Stove...
- Page 2 130102- 1 GF 370 DV MV 2/22 THIS OWNER’S MANUAL PROVIDES INFORMATION TO ENSURE SAFE INSTALLATION AND EFFICIENT, DEPENDABLE OPERATION OF YOUR FIREPLACE INSERT. PLEASE READ THESE INSTRUCTIONS IN THEIR ENTIRETY AND MAKE THEM AVAILABLE TO ANYONE USING OR SERVICING THIS GAS APPLIANCE.
-
Page 3: Table Of Contents
Vent Restriction Adjustments ......12 Vent Termination Diagram......13 2. Confirm stove contents. The Jøtul GF 370 DV MV includes the following loose Stove Assembly items shipped in the Miscellaneous Hardware bag; 1. Glass Frame Removal ......14 •... -
Page 4: Specifications
Intertek Testing Services of Middleton, Wall Thermostat ............#750003 Wisconsin. Remote Control ............#224910 In addition, the Jøtul GF 370 DV MV has been tested and listed as a direct vent gas fireplace heater and listed to ANSI Z21.88-2019 • CSA 2.33-2019 and CAN/CGA 2.17-M91. -
Page 5: General Information
130102- 1 GF 370 DV MV 2/22 3. General Information 5. Do not operate this fireplace if any part of it has been THIS HEATER MUST BE INSTALLED AND under water. MAINTAINED BY A QUALIFIED SERVICE Immediately call a qualified service technician to inspect AGENCY. -
Page 6: Safety Information
130102- 1 GF 370 DV MV 2/22 5. Installation 4. Safety Information Stove Location Due to the high operating temperatures this appliance should be located out of traffic and away from furniture and draperies. Maintain proper clearance to In selecting a location for the stove, consider the following combustible mantels and fireplace trim. -
Page 7: Hearth Requirements
Figure 5.1. Top Plate Shims Mobile Home Installation Hearth Requirements The Jøtul GF 370 DV MV can be installed for use in a The Jøtul GF 370 DV MV has been approved for mobile home in the U.S. and Canada provided: installation directly on non-combustible floor materials. -
Page 8: Approved Vent Manufacturers
Approved Vent Manufacturers 7” 7” The Jøtul GF 370 DV MV stove is approved for installation with direct vent chimney components supplied by the Figure 5.3. Alcove and Wall Clearances. following manufacturers: M&G DuraVent, Inc. (Direct Vent Pro Series) ALCOVE SPECIFICATIONS: P.O. -
Page 9: Vertical Termination
130102- 1 GF 370 DV MV 2/22 Vertical Venting and Termination The Jøtul GF 370 DV MV can be vertically vented through a roof or ceiling. Follow these guidelines IMPORTANT Steep roofs, nearby trees, or predominantly windy • JOINT SEALING... -
Page 10: Horizontal Termination
130102- 1 GF 370 DV MV 2/22 Horizontal Termination Figure 6.5. Minimum vent Minimum vertical rise from the vent collar is a 24” pipe sections required for horizontal termination: section vent pipe. See fig. 6.5. Minimum horizontal run A = 12” with NG is 12”... - Page 11 130102- 1 GF 370 DV MV 2/22 Horizontal Termination Clearance 2 1/2” 12 ” 64 mm 3” 76 mm Figure 6.9. Termination Clearance to overhangs. Vent Terminal Air Supply Terminals Prohibited in this Area Figure 6.8. Vent Terminal Clearances - ANSI Z21.88-2019, CSA 2.33-2019, and NFPA 54 / ANSI Z223.1 National Fuel Gas Code.
-
Page 12: Vent Restriction Adjustments
130102- 1 GF 370 DV MV 2/22 Vent Restriction Adjustments The Jøtul GF 370 DV MV features adjustment controls Exhaust Restrictor Adjustment for both intake air and exhaust to accommodate a variety 1. Remove the Trim Rings from the Top Plate. -
Page 13: Vent Termination Diagram
130102- 1 GF 370 DV MV 2/22 A maximum of two 90° or four 45° elbows may be used. Whenever possible, use 45° elbows instead of 90° elbows as these offer less restriction to the flow of flue gases and intake air. -
Page 14: Stove Assembly
130102- 1 GF 370 DV MV 2/22 7. Stove Assembly 1. Glass Frame Removal To access the firebox, use the 4 mm hex key to remove the four socket head screws that attach the glass frame to the firebox. See fig. 7.1. -
Page 15: Gas Pressure
130102- 1 GF 370 DV MV 2/22 Inlet Pressure 3/8” NPT x 3/8” Flare Fitting 1/2” x 3/8” Flare Shut-off Valve Natural Gas: 5.0 WC (1.24 kPa) 7.0 WC (1.74 kPa) Propane: 12.0 WC (2.99 kPa) 14.0 WC (3.48 kPa) 3/8”... -
Page 16: Fuel Conversion
1. Turn off gas supply to the stove. 2. Remove the glass frame. See fig. 7.1. The GF 370 DV MV gas stove is shipped from the factory 3. Loosen the primary air shutter wingnut and push the equipped to burn Natural gas. Propane fuel conversion kit stem all the way back. - Page 17 130102- 1 GF 370 DV MV 2/22 Figure 7.6. Fuel conversion components and pilot assembly detail. Pilot Head Ignitor Pilot Orifice Flame Sensor Primary Air Shutter Injector Remove black rubber gasket Variable regulator tower Figure 7.7. Regulator tower removal and replacement 8.
-
Page 18: High Altitude Adjustment
130102- 1 GF 370 DV MV 2/22 6. High Altitude Adjustment 7. Firebox Panel Installation The decreased atmospheric pressure of higher altitudes af- Skamol Panels and optional fects heat value of gaseous fuels. Most gas suppliers derate Reflective Glass Kit 156817 the gas intended for use at elevations above 2000 feet. - Page 19 130102- 1 GF 370 DV MV 2/22 8. Install Burner Media River Rocks CAUTION: THE ROCKS ARE FRAGILE! SUPPORT THE ASSEMBLY FROM THE BOTTOM AND HAN- DLE CAREFULLY! 1. Engage the River Rock bed with the two center burner pins as shown in fig. 7.12. Either side of the rocks may face outward as desired.
-
Page 20: Tumbled Stones
130102- 1 GF 370 DV MV 2/22 Tumbled Stones Install the stones according to the instructions supplied with that kit. Install the Log Set The three-piece log set includes a bag of ember stones that simulate glowing coals when the burner is operating. -
Page 21: Beachfire Logset
130102- 1 GF 370 DV MV 2/22 Beachfire Logset LOG IDENTIFICATION 1. Log Retainer 22664192 4. Engage the holes in the bottom of Rear Log 2. Left Rear Log 226843 (#2) with the two steel pins (B) at the left rear corner of the burner plate. - Page 22 130102- 1 GF 370 DV MV 2/22 Replace the Glass Frame NEVER USE A POWER TOOL TO TIGHTEN GLASS FRAME HARDWARE. Use the 4 mm hex key provided to secure screws. Wear clean cut resistant gloves when handling theglass and glass frame.
-
Page 23: System Check
130102- 1 GF 370 DV MV 2/22 System Check Flame Appearance / Air Shutter Make sure the glass frame is removed prior to the systems Adjustment check 1. PURGING THE GAS LINE: When lighting the appliance WARNING: for the first time, it will take a few moments to clear the AIR SHUTTER ADJUSTMENTS SHOULD ONLY gas line of air. - Page 24 130102- 1 GF 370 DV MV 2/22 Optional Wall Thermostat or Remote Control Remote Control A remote receiver should be wired to the terminal block the same way the thermostat would be. See the instructions above. Follow the operating Use only a 750 millivolt DC two-wire circuit thermostat instructions included with the Remote Control unit.
-
Page 25: Operation Notes
130102- 1 GF 370 DV MV 2/22 KEEP PILOT CARRY-OVER PORTS CLEAR. Primary Air Shutter Figure 7.17. Air Shutter location. Figure 10.3.. Starfire Glass flame picture. Operation Notes 1. For the first several hours of operation, it is common to detect some odor as the metal and manufacturing materials cure under heat. -
Page 26: Maintenance
130102- 1 GF 370 DV MV 2/22 Glass Panel or Gasket Replacement Maintenance 1. Use the 4 mm hex key to remove the four socket screws that attach the Glass Frame to the firebox. Remove the lower screws first and be sure to adequately support the frame against the firebox while you remove the upper screws. - Page 27 130102- 1 GF 370 DV MV 2/22 lllustrated Part Breakdown Figure 11.1. Firebox Part Identification. No. Part Number Description 9911 Bolt, Hex Cap, M6x45, DIN 933, Class 8.8, Blk 22298392 Simpson DV II Starter Collar, GF 370, MB 9962 Bolt, Hex Cap M6x10 DIN 933 8.8 Ser Flange Blk...
- Page 28 130102- 1 GF 370 DV MV 2/22 Figure 11.2. External parts identification No. Part Number Description Part Number Description 117874 Bolt, Hex Hd M8 x 16 Ser Flange, Blk 22558492 Hinge, Door, MB 99115 Bolt, Hex Hd M8 x 12 Ser Flange, Blk...
- Page 29 130102- 1 GF 370 DV MV 2/22 Figure 11.3. GF 370 DV MV Spud assembly parts identification...
- Page 30 130102- 1 GF 370 DV MV 2/22 Part Number Description Use only genuine Jøtul Replacement Parts avail- able from your local Authorized Jøtul Dealer or 118218 Screw, HWH SMA 8 x 1.5” SL Zinc by contacting: 223204 Pilot Air Deflector, GF 370 Jøtul North America...
- Page 31 130102- 1 GF 370 DV MV 2/22 This Page is intentionally left blank...
- Page 32 130102- 1 GF 370 DV MV 2/22 This Page is intentionally left blank...
- Page 33 130102- 1 GF 370 DV MV 2/22 12. Jøtul GF 370 DV MV Limited Warranty This warranty policy applies to gas products identified by Jøtul, Scan, and 2) Damage due to incorrect installations not in conformance with the installation instructions contained in this owner’s manual or local and/or national fire and Atra trade names, as set forth below.
- Page 34 Please record the serial number in the space below. You may also wish to attach your purchase receipt to this page for future reference. MODEL NAME: Jøtul GF 370 DV MV Gas Stove SERIAL NUMBER:_______________________________ PURCHASE DATE: ____________________________...
-
Page 35: Lighting Instructions
130102- 1 GF 370 DV MV 2/22 LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. This appliance has a pilot which must be lit by hand. - Page 36 130102- 1 GF 370 DV MV 2/22 This appliance must be installed in conformance with local and national building regulations. Before beginning the installation, it is important that the these instructions be carefully read and understood. Jøtul maintains a policy of continual product development.
