Table 2 describes the switch settings for MAX66301 EV kit. SW1 is reserved for future use. SW3 switch positions 1 to
4 are reserved for future use and position 5 selects between UART or SPI port selection. SW4 resets the MAX66301
during evaluation if needed.
Table 2. MAX66301 EV Kit Switches
REFERENCE
DESIGNATOR
SW1
SW3
SW3
SW3
SW3
SW3
SW4
www.analog.com
POSITION
PUSH 1
Switch 1
Switch 2
Switch 3
Switch 4
Port select
Reset MAX66301
Evaluates: MAX66301 and MAX66250
ON POSITION
(SIGNAL IS GROUNDED)
Not used
Not used
Not used
Not used
Not used
UART port selection
Push—MAX66301 in reset

Ordering Information

PART
MAX66301-25XEVKIT#
#Denotes RoHS compliant.

OFF POSITION

(SIGNAL IS PULLED UP)
Not used
Not used
Not used
Not used
Not used
SPI port selection
MAX66301 normal
TYPE
EV System
Analog Devices │ 9
