MAX66301-25x Evaluation Kit
50Ω Shielded Antenna PCB Bill of Materials
COMMENT DESCRIPTION
20pF CAP CER 20PF 100V NP0 0805
22pF CAP CER 22PF 250V NP0 0805
56pF CAP CER 56PF 100V NP0 0805
47pF CAP CER 47PF 200V C0G/NP0 0805
CONN SMA RCPT STR
SMA
50OHM EDGE MNT
RES SMD 3.3K OHM
3.3k
1% 1/8W 0805
MACH SCREW PAN HEAD
Screw
SLOTTED 6-32 1/2 inch
HEX STANDOFF
Stand Off
#6-32 NYLON 5/8"
50Ω Shielded Antenna PCB Schematic Diagram
www.analog.com
Evaluates: MAX66301 and MAX66250
DESIGNATOR FOOTPRINT
C2 CAP0805-3D
C3 CAP0805-3D
C4 CAP0805-3D
C5 CAP0805-3D
J1 SMA2MALE-3D
R1
MechSC5, MechSC6,
MechSC7, MechSC8
MechSO5, MechSO6,
MechSO7, MechSO8
QTY PART NUMBER
1 08051U200FAT2A
1 251R15S220FV4E
1 08051U560FAT2A
1 08052U470FAT2A
1
0805-3D 1 CR0805-FX-3301ELF
— 4
— 4
