Intellisystem IT-ES215-IU Series Hardware Installation Manual

【Introduction】

IT-ES215-IU series is a type of industrial Ethernet switch, it supports IEEE802.3, EEE802.3u, IEEE802.3x standard, can provide economical
solution for your network connection. IP40 grade protection ensures reliable work in terrible environment. LED indicator is helpful to monitor and
control the status of network connection.
IT-ES215-IU series can provide 3～5 Ethernet ports and 0～2 fiber ports(IT-ES215-IU: 5 Ethernet ports; IT-ES215-IU-1F: 4 Ethernet ports, 1 fiber port;
IT-ES215-IU-2F: 3 Ethernet ports, 2 fiber ports) Ethernet port (RJ45) supports 10/100Base-T(X), full/half duplex, MDI/MDI-X auto-connection;
fiber port is 100Base-FX, multi-mode (M)/ single-mode(S), SC/ST optional.

【Packing List】

The IT-ES215-IU series switch is shipped with following items.
IT-ES215-IU Ethernet switch(Plus Terminal Block) ×1
Hardware Installation Guide ×1
DIN-Rail setting fittings(wall mounting for optional)
The equipment built-in precision devices, please note gently, avoiding excessive vibration to avoid affecting device performance. If you find the
equipment was damaged in transit or any parts are missing, please inform our company or the dealer, we will give you proper s olution as soon as
possible.

【Features】

Support IEEE802.3, IEEE802.3u, IEEE802.3x Standard
Support Auto-Negotiation technology, full/half duplex mode
Plug-and-play, MDI/MDI-X auto connection
Store and forward
LED light indicates the status of network
12～48VDC dual power supply
-40～75℃ operating temperature
Industrial grade design, IP40 protection, metal shell.
IT-ES215-IU series
Unmanaged Industrial Ethernet Switch
Hardware Installation Guide
1
