The UL Listed equipment at the TCC plays a key role in the operation of every Telguard device. All
Telguard units utilize the TCC due to the panel alarm signal format encoding and decoding
requirements used in packet-data transmissions. The TCC also manages the real-time databases for
Telguard
conditions include programming setup information, alarm transmission information, supervisory
trouble information, Check Status information, and automatic self-test information.
TG-7 Dual Path Series communicators come in several versions configured to work either with the
AT&T or Verizon networks:
Model
TG-7E
TG-7FE
NOTE: TG-7 Dual Path Series communicators can be used as either a Primary or Secondary Path
device when an alternate communications path is connected to another alarm panel DACT
connection. In such cases, the panel determines the alarm reporting path.
NOTE: While working in Canada, the communicator may use Rogers Wireless, Bell Mobility, Telus,
or SaskTel cellular networks.
TG-7 Dual Path Series Installation & Operating Guide
Version Application
TG-7E-A
Dual Path Communication for Burglary
Systems in United States and Canada
(AT&T)
TG-7E-V
Dual Path Communication for Burglary
Systems in United States
(Verizon)
TG-7FE-A
Dual Path Communication for Fire or Burglary
Systems in United States and Canada
(AT&T)
TG-7FE-V
Dual Path Communication for Fire or Burglary
Systems in United States
(Verizon)
2 56052601
UL/ULC Standards
UL 1610, ULC-S304
UL 1610
UL 1610, ULC-S304,
UL 864, ULC-S559
UL 1610, UL 864
