LED Indicator Guide
This communicator has a Received Signal Strength Indication (RSSI) Mode that works similarly to the bars on a
cellular telephone. LEDs 2 through 5 will illuminate to represent the quality of the cellular connection: the more
LEDs illuminated (i.e., the higher the number of bars), the better.
A simple press and release of the RSSI button will place the communicator in RSSI mode and another simple
press will exit RSSI mode. Note that while the RSSI button is held in, LEDs 2-5 will blink in unison once per
second.
RSSI Value
NO SVC
1
1½
2
2½
3
3½
4
NOTE: When LED 1 is on in RSSI mode, it indicates more than one cellular tower within range.
TG-7 Dual Path Series Installation & Operating Guide
RSSI Mode
Illuminated
LED 5 = slow flash, LEDs 4-2 = off
LED 5 = on, LEDs 4-2 = off
LED 5 = on, LED 4 = slow flash, LEDs 3-2 = off
LEDs 5-4 = on, LEDs 3-2 = off
LEDs 5-4 = on, LED 3 = slow flash, LED 2 = off
LEDs 5-3 = on, LED 2 = off
LEDs 5-3 = on, LED 2 = slow flash
LEDs 5-2 = on
RF dBm
N/A
≤ -111
 -110
 -100 (Minimum recommended
for dual path)
 -90 (Minimum recommended
for sole path)
 -80
 -70
 -60
