Locking clasp (CliniMACS
Formulation Unit)
Figure 4.5: Right-side view of the CliniMACS Formulation Unit installed on the CliniMACS Prodigy
5.
Make sure that the CliniMACS Prodigy is switched off before connecting the
CliniMACS Formulation Unit. Plug the Power-CAN plug of the CliniMACS
Formulation Unit into the "Power-CAN" connector located on the
Connector Panel of the CliniMACS Prodigy (see Figure 4.5). Refer to
CliniMACS Prodigy User Manual (Instrument) for more information on the
Power-CAN connector. Carefully connect the plug to the socket to avoid
damaging the connector pins. The connector fits only in one position.
Check the orientation if the plug does not slide in smoothly.
6.
After mounting and plugging the CliniMACS Formulation Unit, switch on
the CliniMACS Prodigy. The operator can survey the valves and the liquid
sensor of the CliniMACS Formulation Unit using the test tools provided in
the CliniMACS Prodigy (software version higher than 1.4.19) and document
the installation and operation of the instrument if necessary. Contact
Miltenyi Biotec Technical Support to request the test documentation.
