4.4.2 Unpacking

1. Open the top carton by cutting the adhesive tape.
2. Open the carton and remove any loose content (for example, the
CliniMACS Formulation Unit User Manual).
3. Lift the CliniMACS Formulation Unit together with the protective foam.
4. Remove the protective foam and unwrap the shipping bag around the
CliniMACS Formulation Unit.

4.4.3 Installation

1. Attach the two rubber pads provided onto the bag compartment of the
CliniMACS Prodigy as shown in Figure 4.3 and insert the bag compartment
back into the CliniMACS Prodigy.
Bag compartment
(CliniMACS Prodigy)
Figure 4.3: Placement of the rubber pads on the bag compartment of the
CliniMACS Prodigy (top view)
2. Hold the CliniMACS Formulation Unit with the mounting guide facing the
CliniMACS Prodigy.
3. Tilt the Formulation unit as shown in Figure 4.4 and insert the mounting
guide into the bag compartment of the CliniMACS Prodigy.
Rubber pads
