4.3 Components of the CliniMACS Formulation Unit

The following section describes the components of the CliniMACS Formulation
Unit.
The key components of the CliniMACS Formulation Unit are the 13 pinch valves,
the liquid sensor, the mounting guide, the power cable, and the locking clasp
(see Figure 4.1 and Figure 4.2).
The top view of the instrument is shown in Figure 4.1.
F13 F12 F11 F10 F9 F8 F7 F6
Figure 4.1: Top view of the CliniMACS Formulation Unit
The right-side view of the instrument is shown in Figure 4.2.
Figure 4.2: Right-side view of the CliniMACS Formulation Unit
F5 F4 F3 F2 F1
Mounting guide
Liquid sensor
Pinch valves
Mounting guide
Power cable
Locking clasp
