TECHNICAL SPECIFICATION
Recommended maximum length of log bed:
A maximum of 2 extensions is recommended when using Smart Set.
Weight: 90 kg
Electrical system: 12V
BOLTS/NUTS
Definition of the fasteners on following pages.
ADDITIONAL SYMBOLS
The following symbols are used as supplements
to the symbols above to describe the design of
the parts.
Low
Tensilock
Shoulder bolt
Cross screw
Slotted screw
Locking screw
Hex nut
Flange nut
Flat washer
Lock
Countersunk
DIMENSIONS/LENGTH
The dimensions of the fasteners are written as a diameter
measurement (M) ISO 68-1. For bolts, this is followed by
a length measurement. The length of the bolt is measured
from below the head to the tip of the bolt.
(Diameter)
(Length)
M8
x
20
Allen screw
Allen screw (partially threaded)
Hex bolt
Hex bolt (partially threaded)
Flange bolt
Flange screw (partially thread)
Carriage bolt
7
