OnCell G2100 Series User's Manual
ATTENTION
ATA is the answer command. ATS0=<x> is the auto-answer command. The AT&W command
saves the current settings to the modem.
It is much easier to configure auto-answer with OnCell Configurator. On the GSM Setting tab,
select Enable Auto-answer on ___ Rings and enter the desired number of rings.
ATTENTION
If you are answering a call from a PSTN dial-up modem, type AT+CICB=0 to force the
incoming call to be a data call. Type AT+CBST=7, 0, 1 to select bearer type to V.32 modem
(9600 bps). In addition, type AT&W to save the settings. For further information, please refer to
the OnCell G2100 Series AT Commands Guide on the Document and Software CD.
This task can be performed easily in OnCell Configurator. Select the V32. 9600 option and click
Apply to activate the function.
5-5
GSM/CSD Connection
