Summary of Contents for Moxa Technologies oncell G2100 Series
- Page 1 G2100 Series User’s Manual Fourth Edition, November 2007 www.moxa.com/product Moxa Technologies Co., Ltd. Tel: +886-2-8919-1230 Fax: +886-2-8919-1231 Web: www.moxa.com Moxa Technical Support Worldwide: support@moxa.com The Americas support@usa.moxa.com...
- Page 2 The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2007 Moxa Technologies Co., Ltd. All rights reserved. Reproduction without permission is prohibited.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction ....................1-1 Overview..........................1-2 Package Checklist ........................1-2 Features............................ 1-2 Specifications........................... 1-3 Pin Assignments........................1-5 Chapter 2 Getting Started .....................2-1 Product Characteristics ......................2-2 Dimensions ..........................2-2 OnCell G2150I ......................2-2 OnCell G2110, G2110-T ....................2-3 Connecting the Hardware ...................... - Page 4 Flow Control....................... 4-13 2-wire RS-485 Communication (OnCell G2150I Only) ............4-13 Additional Information ......................4-14 Chapter 5 GSM/CSD Connection..................5-1 Overview..........................5-2 Initiating a CSD Connection ....................5-2 Answering a CSD Connection ....................5-4 Chapter 6 Using Short Message Services..............6-1 Sending Short Messages ......................6-2 Reading Short Messages ......................
-
Page 5: Chapter 1 Introduction
Introduction Chapter 1 The OnCell G2100 Series of industrial GSM/GPRS modems provide an easy way to connect your remote RS-232, or RS-422/485 serial devices to GSM and GPRS mobile networks. The following topics are covered in this chapter: Overview Package Checklist... -
Page 6: Overview
Introduction Overview The OnCell G2100 Series modem is a quad-band GSM/GPRS modem that transmits data and short messages (SMS) over GSM/GPRS mobile networks. The modem can be used to improve the efficiency of your maintenance and communication, and does not require a high level of technical knowledge to operate. -
Page 7: Specifications
OnCell G2100 Series User’s Manual Introduction Seperate RS-422/485 interface (OnCell G2150I only) 2.5 KV RMS for 1 minute isolation for all serial signals (OnCell G2150I only) Specifications Cellular Communication Standard Compliance GSM (Global Service for Mobile) and GPRS (General Packet Radio Service) - Page 8 OnCell G2100 Series User’s Manual Introduction Serial Communication Parameters Parity None, Even, Odd, Space, Mark Data Bits 7, 8 Stop Bits 1, 2 Flow Control RTS/CTS, None Transmission Speed 300 bps to 115.2 Kbps RS-422/485 Termination 120Ω, DIP switch controlled (OnCell G2150I only) RS-422/485 Pull 150 KΩ, 1 KΩ...
-
Page 9: Pin Assignments
OnCell G2100 Series User’s Manual Introduction Pin Assignments 5 4 3 2 1 DB9 (Female) for RS-232 Terminal Block for RS-422/485 RS-485* RS-485* RS-232 RS-422* (4-wire) (2-wire) TxD+ TxD+ TxD- TxD- RxD+ RxD+ Data + (B) RxD- RxD- Data – (A) -
Page 10: Chapter 2 Getting Started
Getting Started Chapter 2 This chapter includes instructions on how to install the OnCell G2100 Series modem. The following topics are covered in this chapter: Product Characteristics Dimensions OnCell G2150I OnCell G2110, G2110-T Connecting the Hardware Wiring Requirements SIM Card Installation... -
Page 11: Product Characteristics
OnCell G2100 Series User’s Manual Getting Started Product Characteristics 1. 12-48V DC Terminal Block 2. H/W RESET Button 3. SMA Antenna Connector 9. DIN/Wall Mount Kit 10. Protected SIM Cover 4. Cellular Signal Level LED 5. PWR/GSM/GPRS/Data LED 11. Antenna 6. -
Page 12: Oncell G2110, G2110-T
OnCell G2100 Series User’s Manual Getting Started OnCell G2110, G2110-T 89,30 [3,516"] 76,00 [2,992"] 27,00 [1,063"]... -
Page 13: Connecting The Hardware
OnCell G2100 Series User’s Manual Getting Started Connecting the Hardware This section describes how to connect the OnCell G2100 Series modem to a host PC or serial devices for initial testing and configuration. Wiring Requirements ATTENTION Safety First! Be sure to disconnect the power cord before installing and/or wiring your device. -
Page 14: Sim Card Installation
Built-in mounting appendages allow the modem to be mounted to a flat wall or on a DIN-rail. Follow the intructions below to mount the modem on a DIN-rail. ATTENTION Before mounting the OnCell G2100 Series modem, we strongly recommend that you first remove the antenna connection. - Page 15 OnCell G2100 Series User’s Manual Getting Started STEP 1: STEP 2: Use a flat-blade screw driver to pull the Hook the modem over the top edge of the bottom mounting appendage out. It should DIN-rail as shown. snap into place.
- Page 16 OnCell G2100 Series User’s Manual Getting Started ATTENTION Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). There are two grounding points for the unit. One point is the 3-pin terminal block connector for power. Underneath the bottom mounting appendage is another grounding point.
-
Page 17: Wall Mounting
OnCell G2100 Series User’s Manual Getting Started Wall Mounting Follow the intructions below to mount the OnCell Series modem on a wall: STEP 1: STEP 2: Remove the 3-pin power terminal block. For Use a flat-blade screw driver to pull out both the OnCell G2150I, also remove the 5-pin the top and bottom mounting appendages. -
Page 18: Connecting The Antenna
Observe any warning signs and manufacturers’ recommendations. All OnCell G2100 Series modems are shipped with a 0 dBi antenna with SMA connector and magnetic mount. The 3-meter patch cord is ideal for installing the modem in places such as a metal cabinet or a vending machine. -
Page 19: Connecting A Serial Device
OnCell G2100 Series User’s Manual Getting Started A terminal block adaptor with power jack connector is provided to connect to AC power instead of DC power. Compatible AC power adaptors are listed on the Moxa website, www.moxa.com. ATTENTION Always install the antenna first and then connect power. Do not connect power if the antenna has not been installed! Doing so may damage the unit. -
Page 20: Led Indicators
OnCell G2100 Series User’s Manual Getting Started Serial Interface RS-232 RS-422 4W RS-485 2W RS-485 Termination Resistor Enabled Disabled Pull High/Low Resistor 1 KΩ 150 KΩ LED Indicators Name Color Function SIGNAL Green Signal level (data transmission requires at least 2 bars) -
Page 21: Chapter 3 Oncell Configurator
OnCell Configurator Chapter 3 Most modems are configured using AT commands. Moxa's OnCell Configurator provides an easy and convenient alternative to configure the OnCell 2100 Series modem. This chapter covers the following topics: Overview Installing OnCell Configurator Launching OnCell Configurator Configuring Serial Connection and Device Name Configuring the PIN Setting Configuring the Radio Band... -
Page 22: Overview
OnCell G2100 SeriesI User’s Manual OnCell Configurator Overview OnCell Configurator is a PC-based utility for managing and configuring your OnCell G2100 Series modem. With its Windows-based graphical interface, even first-time users will find it easy to learn. You can configure general settings, modes, and dial-out parameters without any knowledge of the associated AT commands. -
Page 23: Installing Oncell Configurator
OnCell G2100 SeriesI User’s Manual OnCell Configurator Installing OnCell Configurator To install OnCell Configurator, follow the instructions below. After installation, users will be able to use the Configurator, Wizard, and Terminal Emulator for further operations. ATTENTION OnCell Configurator supports Windows 2000, XP, 2003, and Vista. Find the installation file on the Document and Software CD. - Page 24 OnCell G2100 SeriesI User’s Manual OnCell Configurator Choose I accept the agreement and click Next. Click Next to proceed.
- Page 25 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click Next, or browse to a proper folder to proceed. Click Next to proceed.
- Page 26 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click Next to proceed. Click Install to start the software installation.
- Page 27 OnCell G2100 SeriesI User’s Manual OnCell Configurator Wait until the installation is complete. Click Next to proceed.
-
Page 28: Launching Oncell Configurator
OnCell G2100 SeriesI User’s Manual OnCell Configurator Click Finish. Launching OnCell Configurator Start OnCell Configurator from the Windows Start menu. - Page 29 OnCell G2100 SeriesI User’s Manual OnCell Configurator Select one of the three options: Whether you use the Configurator or the Wizard, any modifications to the settings will not go into effect until you click Apply.
-
Page 30: Configuring Serial Connection And Device Name
The following instructions explain how to configure the serial communication parameters using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 31 The following instructions explain how to configure the serial communication parameters using Wizard. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
- Page 32 OnCell G2100 SeriesI User’s Manual OnCell Configurator On the Configure the Serial Interface page, click Modify and configure the serial device settings. Enter the device name in the text input box. 3-12...
-
Page 33: Configuring The Pin Setting
The following instructions explain how to configure the PIN code using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 34 The following instructions show how to configure the PIN code using Wizard. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
-
Page 35: Configuring The Radio Band
The following instructions illustrate how to configure the radio band using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 36 The following instructions illustrate how to configure the radio band using the Wizard. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
-
Page 37: Initial Strings
The following instructions illustrate how to configure the initial strings using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. -
Page 38: Saving The Configuration Profile
The following instructions illustrate how to configure the serial communication parameters using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 39 OnCell G2100 SeriesI User’s Manual OnCell Configurator Select Save File from the File menu. Select a folder and enter the file name for the profile. Click Save. 3-19...
-
Page 40: Applying Modem Settings
The following instructions illustrate how to apply the current settings to an OnCell G2100 Series modem using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 41 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click Apply. Select the appropriate COM port and communication parameters for connecting to the modem. Click OK to proceed. ATTENTION If you are not sure which communication parameters you should use, please select the Auto Detect Serial Settings option and follow the onscreen instructions.
- Page 42 OnCell G2100 SeriesI User’s Manual OnCell Configurator Wait a few moments for the settings to be applied. Click OK to finish. 3-22...
-
Page 43: Retrieving The Modem Settings
The following instructions illustrate how to use Configurator to get the current settings of an OnCell G2100 Series modem. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 44 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click the Get Settings button on the right side of the window. Select the appropriate COM port and communication parameters for connecting to the modem. Click OK to proceed. ATTENTION If you are not sure which communication parameters you should use, please select the Auto Detect Serial Settings option and follow the onscreen instructions.
- Page 45 OnCell G2100 SeriesI User’s Manual OnCell Configurator Wait a few moments for the settings to be retrieved. Click OK when prompted. The settings will be displayed in the Configurator window. The current firmware version will also be displayed. 3-25...
-
Page 46: Loading A Profile
The following instructions illustrate how to load a profile using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 47 The following instructions illustrate how to load a profile using the Wizard. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
- Page 48 OnCell G2100 SeriesI User’s Manual OnCell Configurator Start OnCell Configurator and select the Load an existing Configuration file to Configurator option. Select a folder and profile and click Open. 3-28...
- Page 49 OnCell G2100 SeriesI User’s Manual OnCell Configurator The modem configuration stored in the profile will be displayed in Configurator. 3-29...
-
Page 50: Signal Strength Monitor
The following instructions illustrate how to configure the serial communication parameters using Configurator. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 51 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click the Sig. Strength button on the right side of the window. Select the appropriate COM port and communication parameters for connecting to the modem and click OK to proceed. ATTENTION If you are not sure which communication parameters you should use, please select the Auto Detect Serial Settings option and follow the onscreen instructions.
-
Page 52: Upgrading The Firmware
The following instructions illustrate how to use Configurator to upgrade the firmware of an OnCell G2100 Series. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 53 OnCell G2100 SeriesI User’s Manual OnCell Configurator Start OnCell Configurator and select Create a new Configuration File from Configurator. Click Upgrade FW on the right side of the window. Upgrading the firmware will clear all current configuration settings in the OnCell G2100 Series modem.
- Page 54 OnCell G2100 SeriesI User’s Manual OnCell Configurator Select a firmware file from the disk and click Open to proceed. ATTENTION Be sure to use the right firmware image file for your model. The OnCell G2110 and OnCell G2110-T both use the same firmware image file. The OnCell G2150I uses a different firmware image file.
- Page 55 GPRS LED is ON or blinking, you must remove the SIM card, or use the escape command (+++) on the terminal to disconnect the current connection. The default parameters are 115200, 8n1, and RTS/CTS flow control. Wait a few moments for the firmware to be downloaded to the OnCell G2100 Series modem. Click OK to finish. 3-35...
-
Page 56: Setting Modem Defaults
The following instructions illustrate how to use Configurator to load the factory default settings into the OnCell G2100 Series modem. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 57 OnCell G2100 SeriesI User’s Manual OnCell Configurator Click Set Defaults on the right side of the window. Select the appropriate COM port and communication parameters for connecting to the modem and click OK to proceed. ATTENTION If you are not sure which communication parameters you should use, please select the Auto Detect Serial Settings option and follow the onscreen instructions.
- Page 58 Wait a few seconds for the default settings to load and click OK to finish. On recent hardware revisions of the OnCell G2100 Series modem, default settings can be restored using the reset button. Simply hold the RESET button down for 10 seconds and the modem will be reset to the factory default settings.
-
Page 59: At Command Set
AT Command Set Chapter 4 The AT Command Set can be used to operate, configure and query the OnCell G2100 Series modem. This chapter includes information about the AT Command Set of the OnCell G2100 Series modem. The following topics are covered in this chapter:... -
Page 60: At Command Set Introduction
AT command set is an industry-standard language that is used to communicate with modems. The OnCell G2100 Series modem is always either in command mode or in on-line mode. When first powered up, the modem will enter command mode. The modem will only accept commands when it is in command mode. -
Page 61: Starting Moxa Terminal Emulator
OnCell G2100 Series User’s Manual AT Command Set Starting Moxa Terminal Emulator The following instructions explain how to install the Moxa PComm Lite Package. After installing PComm Lite, you can use the built-in Moxa Terminal Emulator to handle your modem operations. - Page 62 OnCell G2100 Series User’s Manual AT Command Set Select the target COM port and communication parameters. Click OK to open the port. Terminal Emulator will connect to the target COM port.
-
Page 63: At Command Examples
The following examples can give users a better understanding of how to use the AT Commands. ATTENTION Make sure that the RS-232 port of the OnCell G2100 Series modem is connected. For the OnCell G2150I, make sure DIP switch 1 is set to ON. -
Page 64: Radio Band Selection
Canada, and many other countries in the Americas use GSM-850 or GSM-1900. A quad-band industrial cellular modem such as the OnCell G2100 Series modem makes it relatively easy to prepare the product for shipment to different parts of the world. -
Page 65: Pin Code Management
PIN code has been entered three times. Query the Current PIN Status 1. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. Start PComm Terminal Emulator with the current communication parameters (default: 115200 bps, 8 data bits, None parity, 1 stop bit, and no flow control.) -
Page 66: Disable The Facility Lock
Note that users must apply for PUK codes from the mobile service provider. Disable the Facility Lock Disabling the facility lock will allow the OnCell G2100 Series modem to operate without entering the PIN code each time the modem is powered up. - Page 67 PIN Entry function. This function will store the current PIN in its memory and enter it into the OnCell G2100 Series modem each time the system boots up. If the SIM card does not match the current PIN, the Automatic PIN Entry function will be deactivated.
-
Page 68: Serial Line Settings
The default serial communication parameters are 115200 bps, 8 data bits, None parity, RTS/CTS flow control, and 1 stop bit. Before changing the settings, first connect the RS-232 port of the OnCell G2100 Series modem to a host PC. Open PComm Terminal Emulator with the current communication parameters. -
Page 69: Modifying Data Bits And Parity
OnCell G2100 Series User’s Manual AT Command Set 3. Type AT&W and press Enter to save the settings. Modifying Data Bits and Parity 1. Type AT+ICF=x,y and press Enter, where x and y correspond to the following parameters. 8 data bits, 2 stop bits... - Page 70 OnCell G2100 Series User’s Manual AT Command Set 2. Modify the terminal settings to match the new serial communication parameters. 3. Type AT&W and press Enter to save the settings. ATTENTION Changes to the serial communication parameters take effect immediately. You will need to update your terminal settings to match any changes in the serial communication parameters.
-
Page 71: Flow Control
OnCell G2100 Series User’s Manual AT Command Set Flow Control The default RTS/CTS flow control setting is none. Follow these steps to enable flow control: 1. Type AT+ICF=2,2 and press Enter. To disable flow control again, type AT+ICF=0,0 and press Enter. -
Page 72: Additional Information
Additional Information V.25ter recommendation Commands that are not listed in the OnCell G2100 Series AT Commands Guide (on the Document and Software CD) are not supported. For commands that are not supported, the OnCell G2100 Series modem will respond with “ERROR”. Modulation control, error control, and data compression commands are not recognized. -
Page 73: Gsm/Csd Connection
GSM/CSD Connection Chapter 5 A Circuit-Switched Data Connection makes the wireless modem work in a manner similar to a regular analog modem. You must have CSD service in order to make a CSD call. This chapter covers the following topics: Overview Initiating a CSD Connection Answering a CSD Connection... -
Page 74: Overview
115200 bps, 8 data bits, None parity, 1 stop bit, and no flow control. ATTENTION Check the “SIGNAL” LED indicators on the front panel of the OnCell G2100 Series modem. If the LEDs are all off, then the SIM card is not installed properly, or there is no signal present. - Page 75 OnCell G2100 Series User’s Manual GSM/CSD Connection 2. Type ATD <phone number> and press Enter. For example, type ATD 0289191230 if the phone number is 0289191230. 3. Check the GSM indicator on the front panel of the modem. If the LED is on and an amber color, the CSD connection has been established successfully.
-
Page 76: Answering A Csd Connection
OnCell G2100 Series User’s Manual GSM/CSD Connection Answering a CSD Connection PComm Terminal Emulator can be used to answer a CSD call manually: 1. When the terminal displays "RING", type ATA and press Enter. 2. Check the GSM indicator on the front panel. If the LED is on and an amber color, the CSD connection has been established successfully. - Page 77 (9600 bps). In addition, type AT&W to save the settings. For further information, please refer to the OnCell G2100 Series AT Commands Guide on the Document and Software CD. This task can be performed easily in OnCell Configurator. Select the V32. 9600 option and click...
-
Page 78: Using Short Message Services
GSM technology offers the benefit of using SMS (short message service) as an easy way to communicate over the mobile network. In this chapter, we explain how to use SMS with the OnCell G2100 Series modem. The following topics are covered in this chapter:... -
Page 79: Sending Short Messages
OnCell G2100 Series User’s Manual Using Short Message Services Sending Short Messages Follow these instructions to send a short message to a specific phone number. 1. Type AT+CMGF=1 and press Enter. 2. Type AT+CMGS="<phone number>" and press Enter. The terminal will present a ">"... -
Page 80: Deleting Short Messages
Delete ALL messages. “REC UNREAD” Shows received unread messages. 2. The following example shows how to delete all short messages in the storage. ATTENTION Please refer to the OnCell G2100 Series AT Command Set on the Document and Software CD for additional information on AT commands for SMS. -
Page 81: Sms Tunnel Mode
The following instructions explain how to use Configurator to configure SMS Tunnel Mode. 1. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON. - Page 82 OnCell G2100 Series User’s Manual Using Short Message Services 3. On the SMS Tunnel tab, select SMS-IN to forward incoming short messages to the attached serial device. Select SMS-OUT to transmit serial data from the attached serial device as SMS messages.
- Page 83 The following instructions show how to configure SMS Tunnel mode using the Wizard. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
- Page 84 OnCell G2100 Series User’s Manual Using Short Message Services Select SMS Tunnel Mode and click Next to proceed. ATTENTION Transparent Mode provides the general functions of a GSM/GPRS modem. On the SMS Tunnel Mode Settings page, select SMS-IN to forward incoming short messages to the attached serial device.
- Page 85 The Target Phone Number and Caller ID Verification must be written in international format, starting with “+” followed by the country code. If you leave Caller ID Verification blank, the OnCell G2100 Series modem will allow all incoming short messages to be forwarded to the attached serial device. This includes system broadcasts and advertisements.
-
Page 86: Chapter 7 Gprs Connection
GPRS Connection Chapter 7 The following topics are covered in this chapter: GPRS Overview Windows GPRS Access Installing Modem Driver Modem Diagnostics Setting up the APN Adding Windows DUN Entr... -
Page 87: Gprs Overview
IP network and the Internet. The OnCell G2100 Series modem is a multi-slot Class 10 device, which means that there are 4 Rx timeslots plus 1 Tx timeslot, or 3 Rx timeslots plus 1 Tx timeslot. This requires that the provider support CS-1 to CS-4 coding schemes. -
Page 88: Installing Modem Driver
OnCell G2100 Series User’s Manual GPRS Connection Installing Modem Driver 1. In the Control Panel, open “Phone and Modem Options” and go to the “Modem” tab. Click Add to add a new modem. ATTENTION The first time you access the Phone and Modem Options, Windows will ask you to input the area code. - Page 89 OnCell G2100 Series User’s Manual GPRS Connection 3. Next, click Have Disk. 4. When the Install From Disk window opens, click Browse. 5. Select the OnCell_G2100_Series.inf driver. The file is located in the Win_Driver directory on the Document and Software CD. Click Open to proceed.
- Page 90 OnCell G2100 Series User’s Manual GPRS Connection 6. When the Install From Disk page opens, click OK. 7. Click Next.
- Page 91 OnCell G2100 Series User’s Manual GPRS Connection 8. When the next window opens, select the COM port that you are using and click Next. 9. A message will appear stating that the driver has not passed Windows Logo testing. Click...
- Page 92 OnCell G2100 Series User’s Manual GPRS Connection 10. Click Finish to complete the installation procedure. 11. At this point, the OnCell G2100 Series driver should be listed in “Phone and Modem Options” on the “Modems” tab.
-
Page 93: Modem Diagnostics
Properties. ATTENTION Make sure that the RS-232 port of the OnCell G2100 Series modem is connected. For the OnCell G2150I, make sure DIP switch 1 is set to ON. Make sure the SMS Tunnel Mode is disabled. If the GSM LED is blinking, that means that SMS Tunnel Mode is enabled and activated. - Page 94 OnCell G2100 Series User’s Manual GPRS Connection 2. On the Diagnostics tab, click Query Modem. 3. If the query is successful, you will be able to see commands that are sent to the modem and the modem's responses.
-
Page 95: Setting Up The Apn
The following instructions explain how to set up the APN. ATTENTION Check the signal strength indicators on the front panel of the OnCell G2100 Series modem. If the LED indicators are dark, then the SIM card is not installed properly, or the modem is not picking up a signal. - Page 96 OnCell G2100 Series User’s Manual GPRS Connection 2. On the Advanced tab, enter the following in the Extra initialization commands field: AT+CGDCONT=1,"IP","<APN>" For <APN>, use the correct service for your account, as in this example; AT+CGDCONT=1,"IP","ISP.CINGULAR ATTENTION The APN should be entered between the displayed brackets. Remember that the APN is case sensitive.
-
Page 97: Adding Windows Dun Entry
OnCell G2100 Series User’s Manual GPRS Connection Adding Windows DUN Entry The following instructions explain how to add a Windows Dial-up Networking entry. 1. In the Control Panel, open Network Connections and click Create a new connection. 2. When the New Connection Wizard window opens, select Connect to the Internet and click Next. - Page 98 OnCell G2100 Series User’s Manual GPRS Connection 4. Select Connect using a dial-up modem and click Next. 5. Enter the name of your service provider and click Next. 7-13...
- Page 99 OnCell G2100 Series User’s Manual GPRS Connection 6. Enter *99***1# for the phone number and click Next. ATTENTION The phone number *99***1# is a special phone number that is used globally to request GPRS IP service from the carrier. DO NOT modify this phone number in any way. The same number is used regardless of the country that you are located in.
- Page 100 OnCell G2100 Series User’s Manual GPRS Connection ATTENTION For a list of User names and Passwords, refer to APN List on the Document and Software CD, or consult your service provider for further details. 8. Click Finish. 9. In the next window that opens, click Properties.
- Page 101 OnCell G2100 Series User’s Manual GPRS Connection 10. Verify that Use dialing rules on the General tab is NOT selected. 11. On the Networking tab, select Internet Protocol (TCP/IP) and click Properties to set the DNS IP address. 7-16...
- Page 102 OnCell G2100 Series User’s Manual GPRS Connection 12. If you know the IP address of the DNS server, select Use the following DNS server addresses and enter the IP address(es) as prompted. Click OK. ATTENTION For detailed DNS information, please refer to the APN List on the Document and Software, or consult your service provider for further details.
- Page 103 OnCell G2100 Series User’s Manual GPRS Connection 13. Click OK. 14. In the next window that appears, click Dial to establish the connection. 7-18...
- Page 104 However, for some applications it is either inconvenient or impossible to connect to the embedded computers with a traditional landline. In this case, the OnCell G2100 Series modem is a great solution for providing GSM/GPRS connectivity to the UC-7110 or UC-7112.
-
Page 105: Appendix B Federal Communication Commission Interference Statement
Federal Communication Commission Appendix B Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
