OnCell G2100 SeriesI User's Manual
5. Wait a few moments for the signal strength and the carrier information to be queried. Click
OK to finish.
Signal Strength Indicator

Upgrading the Firmware

The following instructions illustrate how to use Configurator to upgrade the firmware of an OnCell
G2100 Series.
1. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell
G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
ATTENTION
The RS-232 connector uses the standard pinouts. A direct male DB9 to female DB9 cable, such as
Moxa's CBL-F9M9-150 (100 cm) or CBL-F9M9-20 (20 cm), can be used to connect to a PC's
serial port. If you use a USB-to-serial product to configure the OnCell G2100 Series modem, we
strongly recommend using Moxa's UPort 1110. Other USB-to-serial products may cause
unexpected errors when configuring the OnCell G2100 Series modem.
Description
None No signal, or SIM card is not installed properly
1 bar Weak or insufficient (SMS only)
Average (good for GSM CSD and GPRS connections)
2 bars
3 bars Exceptional (good for GSM CSD and GPRS connections)
3-32
OnCell Configurator
