OnCell G2100 SeriesI User's Manual
ATTENTION
Use the command AT+IPR=0 to enable Autobauding. Please refer to Chapter 4 for details.
Autobauding and the +++ escape command only work with 8n1 and e71 settings. Using other
settings will disable these functions.
Stop bits can only be set to 2 only when parity is set to none.
The default parameters are 115200, 8n1, and RTS/CTS flow control.
The following instructions explain how to configure the serial communication parameters using
Wizard.
1. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell
G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
2. Start OnCell Configurator and select the Create a new Configuration File from Wizard
option.
3-11
OnCell Configurator
