OnCell G2100 Series User's Manual
Connecting the Antenna
ATTENTION
Make sure the transmitter antenna is placed so that it is at least 20 cm (8 inches) away from any
people or users. The modem is not designed for applications where users will be in close
proximity for prolonged periods.
Turn the unit off for the following situations:
Respect any restrictions on the use of radio equipment, especially around fuel depots, chemical
plants, and blasting operations.
The OnCell G2100 Series modem may present a hazard for inadequately protected personal
medical devices such as hearing aids and pacemakers. Consult the manufacturer of the medical
device to determine if it is adequately protected.
The OnCell G2100 Series modem may cause interference for inadequately protected electronic
equipment. Observe any warning signs and manufacturers' recommendations.
All OnCell G2100 Series modems are shipped with a 0 dBi antenna with SMA connector and
magnetic mount. The 3-meter patch cord is ideal for installing the modem in places such as a metal
cabinet or a vending machine.
Connecting Power
The power connector is a 3-pin terminal block. It can connect to different types of field power
sources that support 12 to 48 VDC. When power is connected, the "PWR" LED will light up. It
will glow a steady green when the system is ready.
When in an aircraft
When around gasoline or diesel-fuel pumps and before filling your vehicle with
fuel
When in hospitals and any other place where medical equipment may be in use
V+ V- V-
V+
2-9
Getting Started
