OnCell G2100 SeriesI User's Manual
3. On the Init. Strings tab, enter the initial string in the text input box.
ATTENTION
A maximum of 39 characters is allowed for each initial string.

Saving the Configuration Profile

The following instructions illustrate how to configure the serial communication parameters using
Configurator.
1. Connect the RS-232 port of the OnCell G2100 Series modem to a host PC. On the OnCell
G2150I, make sure the RS-232 port is connected and DIP switch 1 is set to ON.
2. Start OnCell Configurator and select Create a new Configuration File from Configurator.
3-18
OnCell Configurator
