OnCell G2100 Series User's Manual
4. Type AT&W and press Enter to save the settings. Note that because the local echo is disabled,
users will no see any response from the modem at the terminal screen.
5. On the bottom of the modem, set DIP switch 1 to OFF, DIP switch 2 to ON, and DIP switch 3
to ON. This configures the modem for 2-wire RS-485 communication.

Additional Information

V.25ter recommendation
Commands that are not listed in the OnCell G2100 Series AT Commands Guide (on the
Document and Software CD) are not supported. For commands that are not supported, the
OnCell G2100 Series modem will respond with "ERROR". Modulation control, error
control, and data compression commands are not recognized. An "ERROR" string will be
returned.
GSM 07.05 recommendation
07.05 commands that are not described in this manual will not be implemented. An
"ERROR" string will be returned.
GSM 07.07 recommendation
07.07 commands that are not described in this manual will not be implemented. An
"ERROR" string will be returned
The ATQ1 command for "Result Code Suppression – not transmitted" is not supported.
Moxa's proprietary AT commands are supported by firmware versions V1.2 and later. Please
refer to the OnCell G2100 Series AT Commands Guide on the Document and Software CD
for further information.
AT&W is entered here.
OK is the response from the
4-14
AT Command Set
modem.
