MISASSEMBLY CHECK
WARNING
!
If your Teeter Inversion Table looks like Image A or B, your inversion table has
been misassembled and is unfit for use. Improper assembly could result in serious injury or death!
Image B Image C
Image A
Go back to Step 4 Proceed to
Go back to Step 3
for instruction. Step 6.
for instruction.
Demonstrates that the Demonstrates that the Table Shows correct assembly.
Roller Hinges have been
Bed has been assembled
assembled upside down
into the A-Frame backwards
into the Table Bed and
so the Main Shaft is not
must be corrected.
resting on the Crossbar and
must be corrected.
13
