Chapter 2: Jumpers and Connectors
Jumpers
LVDS LCD VCC 3.3V/5V/12V Select
Connector type: 2x3 6-pin header
Connector location: JP1
1
2
1
2
5
6
5
6
2-4 Short
3-4 Short
Pin
Status
2-4
Short
LCD VCC = 3.3V
3-4
Short
LCD VCC = 5V
4-6
Short
LCD VCC = 12V
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
1
2
5
6
4-6 Short
Definition
LVDS Inverter VCC 5V/12V/Adapter VCC Select
Connector type: 2x3 6-pin header
Connector location: JP2
2
6
2
1
5
1
2-4 Short
3-4 Short
Pin
Status
2-4
Short
3-4
Short
4-6
Short
9
6
2
6
5
1
5
4-6 Short
Definition
Inverter VCC = 5V
Inverter VCC = 12V
Inverter VCC = Adapter VCC
EBC 355A User Manual
