Block Diagram

LVDS
USB 2.0 x2
USB 2.0
(Front)
USB 2.0 x2
USB 2.0
(Front)
Audio Jack
Audio
Header
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
VGA
VGA
eDP DDI 0
DDI 1
CH7511B
SATA (Port0) SATA 2.0
Port2
GL850G
USB 2.0
Port 0
USB 3.0 USB 3.0
(Back)
Port 0~1
USB 2.0
USB 2.0 (Back)
HD Audio
Realtek
AVL866
PS2 KB/Mouse
GPIO
DDR3L (CH A)
PCIE 2.0
PCIE 2.0
SOC
PCIE 2.0
ValleyView
J1900/N2930
Port 3
USB 2.0
Port 0
PCIE 2.0
Port 1
SATA2.0
FINTEK
F71866A
LPC SIO
23
DDR3L SODIMM
REALTEK 8111G GbeLAN
REALTEK 8111G GbeLAN
Mini PCIeSlot
USB 2.0
USB 2.0 x 2
USB 2.0
(Front)
GL850G
ASM
Mini PCIeSlot
SATA2.0
1453
Or M-SATA
SPI
ROM
Serial 1
(RS232/422/485)
Serial 2~4 (RS232)
