Location of Jumpers (Top View)

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
eDP Backlight VCC Select eDP LCD VCC Select
CMOS Clear
LVDS LCD VCC Select
4
LVDS Inverter VCC Select
COM4 Pin-9 Function Select
COM3 Pin-9 Function Select
COM2 Pin-9 Function Select
COM1 Pin-9 Function Select
Case Open Message Display Function
AT/ATX Select
Security Measure Function Select
