Chapter 2: Jumpers and Connectors
CPU Fan Connector
Connector type: 1x4 4-pin header
Connector location: CPUFAN
4
1
Pin
Definition
1
GND
3
Fan Clock
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
VCC
4
Control
LVDS Inverter Connector
Connector type: 1x8 8-pin header
Connector location: INVERTER
1
Pin
Definition
1
Backlight Enable
3
PVCC
5
GND
7
Backlight Up SW
16
8
Pin
Definition
2
Backlight PWM
4
PVCC
6
GND
8
Backlight Down SW
EBC 355A User Manual
