Chapter 2: Jumpers and Connectors

AT/ATX Mode Select

Connector type: 1x2 2-pin header
Connector location: AT_MODE
2 2
1 1
1-2 Open 1-2 Short
Pin Status
1-2 Open
1-2 Short
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
ATX Mode
AT Mode

Security Measure Function Select

Connector type: 1x2 2-pin header
Connector location: JP7
2 2
1 1
1-2 Open 1-2 Short
Pin Status
1-2 Open
1-2 Short
14
Settings
Enable Security Measures in the
Flash Descriptor (Default)
Disable Security Measures in the
Flash Descriptor (Override)
EBC 355A User Manual
