4400-TRM, 4401-TRM
Carrington
Trim Series
™
Operation & Maintenance Manual
Model Numbers
4400-TRM
Valve Trim
4401-TRM
Shower Trim
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-CRP
Cross handle in place of white
insert handle
-LAM
Metal finish insert handle
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Symmons Industries, Inc.
©2014 Symmons Industries, Inc.
Specifications
Shower trim includes shower escutcheon kit and 3 mode
showerhead with standard 2.5 gpm (9.5 L/min) flow
restrictor. Valve trim includes shower escutcheon kit only.
Components made from metal and nonmetallic materials
plated in standard polished chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
■
■
31 Brooks Drive
Braintree, MA 02184
■
■
www.symmons.com
gethelp@symmons.com
■
■
(800)796-6667
Fax: (800)961-9621
■
ZV-3056 REV A 09/02/14
