Symmons Sereno SK-3500 Installation Manual

Single handle kitchen faucet

Advertisement

Quick Links

SK-3500 (CDSK0196)
Single Handle Kitchen Faucet
Installation Guide
Model Numbers
SK-3500
Single Handle Kitchen Faucet
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
CG
Note: Append appropriate -suffix to model number.
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Dimensions
A A
B B
C C
D D
F F
Note: Dimensions subject to change without notice.
DS Creations
G G
H H
E E
Specification
Single Handle Kitchen Faucet shall include single hole
mount configuration, ceramic cartridge, 3/8" compression
connections and standard 2.2 gpm (8.3 L/min) aerator.
Faucet shall be made from metal construction, plated in
standard polished chrome finish.
Compliance
-ASME A112.18.1/CSA B125.1
-NSF/ANSI 61.9, NSF/ANSI 372
I I
J J
Measurements
A
4-3/8", 111 mm
B
Ø 1-7/8", 48 mm
C
1", 25 mm
D
4-1/8", 105 mm
Deck Thickness Ref.
E
Min. 1", 25 mm
Max. 1-1/4", 32 mm
Hole Size
F
Ø 1-1/2", 38 mm
G
15-1/8", 384 mm
H
9-3/8", 238 mm
I
7-1/4", 184 mm
J
3/8" compression fitting
