Installation
1.
Place the end of the lower sliding channel into the bottom of the side support (Fig. 2) and align the
guide to feed the rope into the top channel.
Lower sliding channel
2.
Slide the lower sliding channel all the way through, leaving a little bit of rope loose at the end. Place
the end cap on the end of the lower sliding channel (Fig. 3).
3.
Loop the extra rope at the end around the end cap to the upper channel and slide with fingers up the
rope to the side support. Make sure that the rope is taut (Fig. 4).
Rev: 05.23.22
Fig. 2
Rope
Fig. 3
Fig. 4
Page 4
End Cap
Rope
Rope
CCD-0006239
