16. Step inside the van and slowly close the screen door.
17. Screw the left side of the upper sliding channel with the two 3.9 x 13 screws to the mounting back with
the screw gun (Fig. 14).
18. Carefully open the screen door and step outside the van.
19. Using an OEM-supplied #8 x 1" screw, insert into the top of the fill panel to secure it to the mounting
back (Fig. 15).
Fill Panel
Rev: 05.23.22
Fig. 14
Mounting Back
Screws
Upper Slide Channel
Fig. 15
Page 8
2X
3.9 x 13
Mounting Back
Screw
