- Page 1 STRINGS ADJUSTMENT TENSION MANUAL FLYSCREEN N-SERIES Plant 310 Whenever, wherever, we make your experience better. TI-429 CCD-0006419...
- Page 2 INTRODUCTION Looking at the flyscreen, keep its sloping side on the right. On the flyscreen there are 5 wire clamp plates: TI-429 CCD-0006419...
- Page 3 ADJUST STRAIGHT SIDE Place the handle of the flyscreen in LEFT RIGHT closed position and hold it. Slightly unscrew the stud bolt N° 1 Increase Decrease or N° 5 as needed with a 2 mm allen wrench until the wire clamp plate is free to move.
- Page 4 ADJUST STRAIGHT SIDE If too much force is required to move the handle, loosen the cords in both the upper and lower tracks slightly. If the handle is moved If the handle is moved When the handle is in forward at the bottom forward at the top of fly the vertical position, it If the rope tension is too...
- Page 5 ADJUST SLOPING SIDE Place the handle of the flyscreen in closed position and hold it. Slightly unscrew the stud bolt N° 3 or N° 4 as needed with a 2 mm allen wrench until the wire clamp plate is free to move. Move the wire clamp plate as shown in the ...
- Page 6 ADJUST SLOPING SIDE If the strings that pass If the crawler tends to throught the net are get stuck, increase the loose, increase the tension of clamp plate If the rope tension is too tension of clamp plate N° 3. high, the handle will be N°4.
