TECHNICAL DESCRIPTION

3.2 Electrical data

Battery
Type
Battery lifetime
EMC data (OIML)
(Elektromagnetisk klasse)
Sigfox classification
Sigfox radio zone

3.3 Materials

Wetted parts
Meter tube, with thread
Meter tube, with flange
O-ring / gasket
Spring ring
Measuring tube
Reflectors
Strainer (filter)
Meter
Meter housing
Cover
Top ring (sealing)
12
3.65 VDC, C-cell lithium
up to 16 years at tBAT < 30 °C – depending on selected module
up to 8 years at tBAT = 30 - 55 °C – Wired and Wireless M-Bus
tBAT max 35 °C for Sigfox versions
In Low Voltage Directive fulfils MID class :
E1 and E2 (for Wireless M-Bus and Sigfox version)
E1 (for Wired M-Bus version)
Class zero
RC1, 868 MHz, 14 dBm
DZR brass – CW511L (resistant to dezincification )
Stainless steel W. no. 1.4408
EPDM
Stainless steel W. no. 1.4310
Polyphenylene sulphide PPS – 40 % fibreglass
DN100 TYPE 2E: Polyarylethersulfone
DN100 type 3E: Polyphenyleneoxide PPO
Stainless steel, W.no. 1.4301, 1.4306, 1.4307, 1.4401, 1.4404
Polyarylethersulfone PES
Polyphenylene sulphide – 40 % fibreglass
Glass
Polycarbonate (dyed – blue)
Kamstrup A/S • Technical Description • 5512-1242_N1_GB • 10.2019
flowIQ® 3100
