- Page 1 Technical Description Wired M-Bus Water Meters flowIQ® 2101/3100...
-
Page 2: Table Of Contents
Temporary error..........................15 Datagram ..............................16 Reading loggers from flowIQ® 2101/3100 wired M-Bus..................17 Configuration of meter via the M-Bus network ....................17 Setting Primary M-Bus address ........................18 Setting Date and time ..........................19 Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... - Page 3 Wired M-Bus • Water Meters flowIQ® 2101/3100 TECHNICAL DESCRIPTION Application select/reset ..........................19 Protocol ................................20 RSP_UD data flowIQ® 2101/3100 data using Kamstrup specified VIFE............20 RSP_SKE response from flowIQ® 2101/3100 ....................25 Data header in RSP_UD ..........................26 DIF (Data Information Field) ........................27 Primary VIF (Value Information Field) ......................
-
Page 4: Introduction
These VIFE codes are formatting the data, whereby decoding of the content is much easier, as when using manufacturer specified data. The connection of the M-Bus water meter and the M-Bus network is realized with a fixed two wire cable. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 5: Physical Properties
Configuring the primary address can be done with METERTOOL HCW using an optical readout head or via the M-Bus network. It is recommended that the entire M-Bus system is not powered up during installation of new M- Bus water meters. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 6: Data Communication
001...250, and the special addresses 0, 253, 254 and 255 • M-Bus ID number: 8 digits 00000000… 99999999 • Manufacturer ID: Always 2D2Ch for ’KAM‘ for Kamstrup M-Bus water meter • Version ID flowIQ® 2101 • Version ID flowIQ® 3100 •... -
Page 7: Primary Addressing
Adr. 255: No M-Bus meter will reply to this address, but all will receive the message. This address makes it possible e.g. to change the baud rate, on an entire system at the same time, by sending only one telegram. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 8: Secondary Addressing
8 byte long complete M-Bus ID consisting of: • M-Bus ID number. Default from Kamstrup: The last 8 digits in the meter number / customer number (4 bytes) • Manufacturer ID = ASCII characters ‘KAM’ for Kamstrup encoded to the value 2D2Ch (2 bytes) •... -
Page 9: Enhanced Secondary Addressing
Fabrication no. (serial no.), e.g.: 2500176 Fabr. no. LSB 76 or FF BCD Fabr. no. 01 or FF BCD Fabr. no. 50 or FF BCD Fabr. no. MSB 02 or FF BCD Checksum Stop character Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 10: Wildcard Search With Break Detection
REQ_UD1 (FCB =1) REQ_UD2 (FCB=0) REQ_UD2 (FCB =1) SND_UD2 Note: In the default application the FCB bit is not used and the M-Bus water meter accepts both FCB = 0 and FCB = 1. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... - Page 11 Kamstrup specific from master to slave Kamstrup specific from slave to master Note: As the flowIQ® 2101/3100 M-Bus water meters supports auto baud rate detection, it is not necessary to instruct them with a specific baud rate. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
-
Page 12: M-Bus Master To M-Bus Water Meter
Short frame. Request for data from the M-Bus interface. Start character C-field 5Bh or 7B A-field xxh or FDh Checksum Stop character REQ_SKE: Short frame. Status request. Start character C-field A-field xxh or FDh Checksum Stop character Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 13: M-Bus Slave To M-Bus Master
The M-Bus water meter checks the message, and if it is correct, the M-Bus water meter returns with an RSP_UD, which is meter data packed according to the M-Bus format for RSP_UD. An example of a RSP_UD datagram can be viewed later in the manual. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 14: Req_Ud1 -> Ack
REVERSE: Meaning that the water is flowing in the wrong direction in the meter. LEAK: Meaning that the water has been running for more than 24 hours. BURST: Meaning that the water flow is constantly high for more than 30 minutes. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 15: Status Field
No info code Power Low on battery Temporary Error Power Low and Temporary Error 5.7.2 Temporary error Temporary Error (Bit 4) is set when one of the info codes is active in flowIQ® 2101/3100. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 16: Datagram
In order to be able to decode special data registers in an easier way, Kamstrup has taken the approach to define a number of manufacturer VIF extensions – so called VIFE. The outcome is that most reading systems can show the special registers in clear reading. -
Page 17: Reading Loggers From Flowiq® 2101/3100 Wired M-Bus
SND_UD telegram from the M-Bus Master to the M-Bus water meter. Selection of device for secondary addressing is made by CI-field = 52h, and application select/reset by CI-field = 50h. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 18: Setting Primary M-Bus Address
XX = 01h... FAh. For primary address = 1... 250 Checksum Stop character Note: During the ordering process the primary address for each meter can be specified. Normally it is the last 2-3 digits of the customer number. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 19: Setting Date And Time
Note: See EN13757-3 Annex A ‘Coding of data records’ for details on how to decode the Date/Time data type. Application select/reset In connection with application reset the flowIQ® 2101/3100 M-Bus water meter returns an ‘ACK’. Nothing further happens and nothing is reset. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 20: Protocol
The flowIQ® 2101/3100 M-Bus water meter only support commands stated in this description. The datagram is fixed. RSP_UD data flowIQ® 2101/3100 data using Kamstrup specified VIFE Complete description of reply with examples of readings from the M-Bus water meter (RSP_UD) on request from... - Page 21 Avg T 26 °C ambient 4 byte binary Type F (Compound CP32) Date/Time E.g. CP32: 23173782h = 2017-03-23 23:02 4 byte binary, monthly value Volume in m with 3 decimals V1 Target 66.976 m Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
- Page 22 00 = no info codes 6 byte binary Kamstrup specific vif: Config number Config Number Config no: 175462DEDDh = 0100200013533 2 byte binary Kamstrup specific vif: Meter type Meter Type Meter Type: flowIQ2101 Cold Water Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
- Page 23 Reverse volume in m with 3 decimals Volume Reverse 0.019 m 4 bytes binary Duration of meter power on in hours Hour Counter 304 hours 2 bytes binary Flow in l/h Flow 5 l/h Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
- Page 24 1 byte binary, monthly maximum value Ambient temperature in °C Max T Month 36 °C ambient 1 byte binary, monthly value Kamstrup specific vif: average ambient temperature Avg T Month 24 °C ambient Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
-
Page 25: Rsp_Ske Response From Flowiq® 2101/3100
But the (empty) RSP_SKE reply to REQ_SKE request ensures, that the M-Bus water meter will function in M-Bus systems with other M-Bus interfaces, supporting time-critical data (alarm protocol) and using communication status bit. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 26: Data Header In Rsp_Ud
04h = Power Low on battery 10h = Temporary error 14h = Power Low and Temporary error at the same time ENCRYPTION Encryption not used in Wired M-Bus CONFIGURATION ENCRYPTION Encryption not used in Wired M-Bus CONFIGURATION Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 27: Dif (Data Information Field)
32 bit binary, Historical Value, Type B OTHERS 00000100 32 bit binary, Current Value, Type B Note: See EN13757-3 Annex A ‘Coding of data records’ for details on how to decode data types. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 28: Primary Vif (Value Information Field)
Min. flow last month m³/h∗10 00111011 Max. flow last month m³/h∗10 01011011 Minimum water temperature °C °C last month 11011011 Average water temperature °C °C last month 01100111 Minimum ambient °C °C temperature last month Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 29: Special Purpose Vif
Description Usage 00001110 Metrology firmware version Legal meter software revision 00010111 Error flags (binary) Meter Error (info) code (see section 5.7.2) Note: See En13757-3 table 28, for a complete list of VIFE codes. Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016... -
Page 30: Technical Description Wired M-Bus • Water Meters Flowiq
TECHNICAL DESCRIPTION Wired M-Bus • Water Meters flowIQ® 2101 3100 --- End of document --- Kamstrup A/S · Technical Description · 55121944_A1_GB_08.2016...
