Two-person team is recommended for assembly.
By now, you have installed your mount kit or free-standing base, with the
required minimum base weight.
Installing Internal Stem
Option A: If you wish to use optional pre-installed internal stem cover, proceed
below. Otherwise, if you wish to not use internal stem cover, skip to Option B
on page 5.
OPTION A:
1. Using a two person team, lift umbrella with attached internal stem and stem
cover, and install internal stem onto mount kit or on your free-standing base.
2. Tighten 4 stem bolts to secure umbrella in place with 5mm hexagon wrench.
NOTE: Do not use power drill. May cause damage to umbrella.
3. Slide internal stem cover down to cover internal stem.
ASSEMBLY INSTRUCTIONS
You are now ready to operate your umbrella!
Proceed to Operating Instructions on page 7.
4
