Summary of Contents for Shademaker ATLAS Series
- Page 1 Owner's Manual ATLAS | ASTRAL SERIES...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page No. Atlas / Astral Diagram Wind Resistance and Guidelines Installation Guidelines Assembly Instructions Operating Instructions How to Properly Fold Canopy Protective Cover Canopy Removal and Replacement Maintanence Safety and Precautions Warranty... -
Page 3: Atlas / Astral Diagram
Please read this entire manual before installing or operating your umbrella. Thank you for purchasing Shademaker's Atlas / Astral center post umbrella. Please remove all contents from packaging, inspect and review diagram. Some parts may be included in the Styrofoam or small packaging. Do not discard any packaging or boxes until assembly is complete. -
Page 4: Wind Resistance And Guidelines
*Permanent mount recommended NOTE: If using a free-standing base, wind guidelines change to light winds only. Using a Shademaker mount kit is always the preferred method of securing your umbrella above all other methods. We recommend a licensed contractor to secure your Shademaker umbrellas. -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS Two-person team is recommended for assembly. By now, you have installed your mount kit or free-standing base, with the minimum required base weight. Installing Internal Stem Option A: If you wish to use optional pre-installed internal stem cover, proceed below. - Page 6 Attach Center Post to Internal Stem 1. Rotate the center post until desired canopy angle is reached and the holes for the locking screw(s) in the internal stem line up in the post. 2. Tighten locking screw(s) into the internal stem to secure in place. NOTE: (1) locking screw for Atlas style, (2) locking screws for Astral style.
- Page 7 OPTION B: If you wish not to use optional internal stem cover, proceed below. 1. With your umbrella laying on a clean soft surface, remove locking screw(s) (1 for Atlas style, 2 for Astral style) from lower end of center post. 2.
-
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Remove all packaging from umbrella parts. To Open Canopy 1. Remove the strap from canopy structure. Take note of the “parachute” folding method used to fold the canopy when closed. See TO PROPERLY FOLD CANOPY section on page 9 for more details. 2. - Page 9 To Close Canopy 1. Insert crank handle into crank gear on center post. Turn crank handle counter- clockwise until umbrella is completely closed. 2. Wrap supplied strap around canopy to secure. NOTE: When fastening strap, make sure that no fabric is caught in between the ribs, as this can result in rubbing and damage to the canopy.
-
Page 10: How To Properly Fold Canopy
TO PROPERLY FOLD CANOPY The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time. -
Page 11: Maintanence
MAINTAINING FRAME & FITTINGS • Hose frame with water periodically, more often if installation is in a salty or industrial environment. • Inspect the installation fitting, mount bolts, rib spacers, etc. on a regular basis and tighten if necessary. MAINTAINING CANOPY FABRIC •... -
Page 12: Safety And Precautions
• Sufficient base weight must be used to secure umbrellas at all times. Please base weight matrix at www.shademaker.com for required minimum weight for free-standing applications. Using a Shademaker mount kit is always the preferred method of securing your umbrella above all other methods. We recommend a... -
Page 13: Warranty
Our only business and focus is shade and shade type products. Our goal is that each and every Shademaker style will exceed your expectations at a competitive price that will make you smile. - Page 14 Irregularities in Production Process: The possibility of “Irregularities” in the product surface may occur during the production process. However, these irregularities do not reduce the quality of the product. Shademaker monitors every stage of production to ensure a clean and consistent appearance on every part.
- Page 15 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademaker.com ©2023 Shademaker. All rights reserved. SMOM-ATLAST-072523...
